Product Description
Air cylinder :SI series
Features:
1.Standard design, simple structure, low starting pressure, smooth motion.
2.Adjustable cushion on both cylinder end covers to make sure the cylinder works very smoothly, safety and with low noise.
3.Wide range for sizes
4.With self-lubricating bearing, the piston rod is lubrication free.
5.Mickey mouse shape tube.
Specifications:
| Bore(mm) | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 160 | 200 |
| Motion Pattern | Double Action | ||||||||
| Working Medium | Air | ||||||||
| Fixed Type | Normal type:FA/FB/CA/CB/LB/TC | ||||||||
| Working Pressure Range | 0.1-0.9MPa | ||||||||
| Ensured Pressure Resisitance | 1.35MPa | ||||||||
| Operating Temperature Range | -5-70°C | ||||||||
| Operating Speed Range | 50-800m/s | ||||||||
| Buffer Type | Adjustable Buffer | ||||||||
| Buffer Stroke | 24 | 32 | |||||||
| Por Size | G1/8" | G1/4" | G3/8" | G1/2" | G3/4" | ||||
We also can supply SI series air cylinder assembly kits.
Other ISO Standard Pneumatic Cylinders are also available for you:
DNG ISO15552 Standard cylinder
DNC ISO6431&VDMA24562 Standard cylinder
MA ISO6432 Mini cylinder
ADVU ISO6431 Compact/Thin cylinder
More information and details,you can contact us and visit our website.
If you have the nonstandard products want to design,don't hesitate to contact us.
