Европейский популярный тонкий модифицированный синусоидальный сигнал dc 12v 24v to ac 110v 220v 230v 240v автомобильный инвертор мощности 1000w с мягким
- Категории: Inverters >>>
- Поставщик: Jiaxing,Solarway,New,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
European popular slim modified sine wave dc 12v 24v to ac 110v 220v 230v 240v car 1000w power inverter with soft start
Company Information
Jiaxing Solarway New Energy Company is a Sino-Germany Joint venture which is a professional off-grid power inverter manufacturer in Jiaxing city ,near to Shanghai,China . We are mainly engaged in high-tech DC TO AC inverter, DC TO DC converter, MPPT/PWM sollar controller, solar panel and other solar system accessories, OEM and ODM service are available.All our products we have CE,RoHs,E-mark certification
We have R & D Center and After-sales Service Center in Beijing, China and Leipzig, Germany to make sure we have new design with patent every year.
Technical Parameters
| MODEL | NM1K-112 | NM1K-124 | NM1K-148 | NM1K-212 | NM1K-224 | NM1K-248 | |
| Output | AC Voltage | 100/110/120VAC | 220/230/240VAC | ||||
| Rated Power | 1000W | ||||||
| Surge Power | Load 120~150%(3min.);2000W(3sec.;resistive) | ||||||
| Waveform | Modified Sine Wave | ||||||
| USB port | 5V 2.1A | 5V 2.1A | ------ | 5V 2.1A | 5V 2.1A | ------ | |
| Input | DC Voltage | 12VDC | 24VDC | 48VDC | 12VDC | 24VDC | 48VDC |
| Voltage Range | 10.5~15VDC | 21~30VDC | 42~60VDC | 10.5~15VDC | 21~30VDC | 42~60VDC | |
| Efficiency(Typ.) | 89%~93% | ||||||
| Remote Control | Function(optional) | ||||||
| Protection | BAT.Low Alarm | 10.5±0.5VDC | 21±1.0VDC | 42±2.0VDC | 10.5±0.5VDC | 21±1.0VDC | 42±2.0VDC |
| BAT.LOW Shutdown | 10±0.5VDC | 20±1.0VDC | 40±2.0VDC | 10±0.5VDC | 20±1.0VDC | 40±2.0VDC | |
| Over Load | Shut down output voltage, restart to recover | ||||||
| Over Voltage | 15.5±0.5VDC | 31±1.0VDC | 62±2.0VDC | 15.5±0.5VDC | 31±1.0VDC | 62±2.0VDC | |
| Over Temperature | Shut down output voltage, recover automatically after temperature goes down | ||||||
| Output Short | Shut down output voltage, restart to recover | ||||||
| DC Input Reverse Polarity | By fuse | ||||||
| Earth Fault | Shut off o/p when the load has electrical leakage | ||||||
| Soft Start | Yes,3~5 Seconds | ||||||
FAQ1
1.Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we accept OEM orders.
2. Q:How to choose a right inverter?
A:Tell us your demand, then our sales will recommend a suitable inverter to you.
3. Q:How about the delivery time?
A: 7 days for sample; 25 days for bulk order.
4. Q:What is the warranty of inverter?
A: Two years warranty.
5. Q:How to solve the technical problem?
A:24 hours after-service consultancy just for you and to make your problem to solveeasily.
6.Q: What kind of output you can do?
A: Normally, we produce inverter with 110v/ 50Hz, 120V/ 60Hz, 220v/ 50Hz, 230v/ 50Hz, 240V/50Hz.If you have special requirements, please tell us for engineer consulting.
7. Q: What appliances your inverters can load?
A: Our inverter can load household appliances other inductive load such as refrigerator, air condition, water pump, etc.
Certificate
Click here for more information
