Turning | |
Maximum workpiece turn around diameter on the machine tool | 125mm |
Maximum workpiece length | 180mm |
Maximum workpiece turn around diameter on the tool holder | 60mm |
Spindle through hole diameter | 9mm |
Spindle cone hole | MT.1 |
Machining metric thread number types | 8 |
Machining metric thread pitch range | 0.4~1.5mm |
Machining imperial thread number types | 8 |
Machining imperial thread pitch range | 0.0028~0.0055 1/n″ |
Longitudinal feed amount series | 2 |
Spindle each time rotated the tool holder longitudinal feed amount | 0.07~0.14mm |
Tailstock sleeve stroke | 18mm |
Tailstock sleeve cone hole | MT.1 |
Spindle speed range and level number | 560~2500 r/min five levels |
Drilling | |
Maximum drilling diameter | 6mm |
Spindle end surface to work surface distance | 120~180mm |
Distance from spindle centerline to column surface | 125mm |
Drilling and milling head box around the column rotation angle | 360° |
Spindle speed range and level number | 500~2500 r/min ten levels |
Drilling and milling head box vertical lifting travel | 60mm |
Milling | |
Working table surface width | 60mm |
Working table surface length | 85mm |
Workbench T-slot width | 8mm |
Spindle sleeve movement amount | 40mm |
Others | |
Motor | 180w,110v,60Hz (220v,50Hz) |
Net weight of machine tool (excluding machine base) | 22KG |
Overall dimensions (length * width * height) | 52×30×41cm |
Net weight/Gross weight | 22KG/25KG |
