3 лезвия 5 лезвий 12 В микро ветровые фрезы 200 Вт для уличного освещения и

Model

RC-200-A

Rated Output

200W

Peak Output

300W

Rated Voltage

12/24V AC

Start-up Wind Speed

2 m/s

Cut-in Wind Speed

3m/s

Rated Wind speed

10m/s

Survival Max. wind

45m/s

Number of Blades

3/5/6

Rotor Diameter

1.18m

Swept Area

1.09

Blade Material

Nylon reinforced composite

Generator Type

3-phase PMA with high performance Neodymium Magnets

Generator case

Casting aluminum alloy

Controller Type

PWM

Over speed control

Automatically adjust windward direction

Net Weight

6.5kg

Tower Connector

Flange or Hoop

Flange Size *

DN20

Tower Type *

Guy Cable Tower

Tower Size *

3mX2, 48-3mm

Working Temp. range

from -40°C to 60°C

Product Life

15 years

Warranty

1 years

Applications

solar & wind hybrid lighting, off-grid power system etc.

Measurement

71*28*20.5cm

Gross Weight

7kg
