Генератор ветряной турбины для жилых помещений 5

Model

RC-5K-A

Rated Output

5KW

Peak Output

7KW

Rated Voltage

48/96/120/220V/380V AC

Start-up Wind Speed

2.5 m/s

Cut-in Wind Speed

3.5m/s

Rated Wind speed

12m/s

Survival Max. wind

45m/s

Number of Blades

3

Rotor Diameter

4.7m

Swept Area

17.34

Blade Material

fiberglass reinforced composite

Generator Type

  3-phase PMA with high performance Neodymium Magnets

Generator case

Casting aluminum alloy

Controller Type

PWM

Over speed control

Automatically adjust windward direction&Tail &tail fold up

Tower Connector

Flange

Flange Size *

DN125

Tower Type *

Guy Cable Tower

Tower Size *

3mX3, 140-4mm

Working Temp. range

from -40°C to 60°C

Product Life

15 years

Warranty

1 years

Applications

on/off-grid solar & wind hybrid system etc.
