Коробка для соединения предохранителей уличного освещения серии HM3 IP54 Пластиковая распределительная

Описание и отзывы

Характеристики

HM3 series IP54 street lighting pole fuse connection box,plastic junction box



1. Body made of polyamide resin 6 self-extinguishing and infrangible

2. Moulded connector made of polyamide resin 6 self-extinguishing

3. Pressed terminals made of 3 ways zinc electro-alloy. Fast assembling on DIN rail. Single connection of the wires by stainless steel screws

4. Double DIN rail to allow 4 cables 3 ways terminal strip 4 *16 sqmm plus one or two fuse carriers(or MCB).

5. Voltage 450V max current 63A.

6. Pole recessed mounting diameter min 89mmThe min dimensions of the door opening of the pole should be 80*300mm

7. Body and terminals class 2 according to CEl64-8/4 standards.

8. Protection rate IP54 along the frame;IK 08 according to CEl EN 50102 standards.

9. Any RAL colour on request.
