Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и
Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и
Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и
Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и
Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и
Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и

Высокопроизводительная спиральная дрель с коническим хвостовиком M2 morse BWIN OEM для сверления стали и


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Procuct Name:
Black Finish Milled DIN345 HSS Morse Taper Shank Twist Drills
Material:
HSS 4241,4341,6542-M2, Cobalt 5% M35 is Available
Process:
Milled (Roll Forged is Available)
Standard:
DIN345 (DIN341, DIN1870 are Also Available)
MT No.:
No.1 to No.6
Size:
6mm-100mm and 3/8" to 4"
Flute Type:
Type N, Right Hand Cutting
Point Angle:
118 Degree (135 Degree Split Point are Available)
Surface Finish:
Black Oxide (Black & White, Gray & Bright, Bright, Amber Color, Titanium Coating are Also available)
Package:
One Piece in Plastic Box.
Features:
1.Precise dimension,long life and high efficiency.
2.High-speed steel (HSS) provides hardness for wear resistance
3.Black oxide finish reduces wear while promoting chip and coolant flow on ferrous materials
4.Self-centering 118-degree notched point penetrates material without a pilot hole more easily than a conventional point, and maintains a sharp cutting edge
5.Morse taper shank allows the tool to be inserted directly into the machine's spindle to facilitate high-torque applications such as large cut diameters
6.When run in a counterclockwise direction (right-hand cut) spiral fluted tools evacuate chips up and out of the cut to reduce clogging
7.Designed to perform in a broad range of materials in the iron and steel families
8.Spiral flutes are constructed with a higher flute angle to remove chips more easily.


Morse Taper Shank Twist Drill Bit








DIN345 Morse Taper Shank Twist Drill Bit


D(mm)
L1
L
MT
D(mm)
L1
L
MT
5~5.3
52
133
1
35.5
190
339
4
5.4~6
57
138
1
36
195
344
4
6.1~6.7
63
144
1
36.5
195
344
4
6.8 ~7.5
69
150
1
37
195
344
4
7.6~8.S
75
156
1
37.5
195
344
4
8.6 ~9.5
81
162
1
38
200
349
4
9.6~10.6
87
168
1
38.5
200
349
4
10.7~11.8
94
175
1
39
200
349
4
11.9~13.2
101
182
1
39.5
200
349
4
13.3~14
108
189
1
40
200
349
4
14.1~15
114
212
2
40.5
205
354
4
15.1~16
120
218
2
41
205
354
4
16.1~17
125
223
2
41.5
205
354
4
17.1~18
130
228
2
42
205
354
4
18.1~19
135
233
2
42.5
205
354
4
19.1~20
140
238
2
43
210
359
4
20.1~21.2
145
243
2
43.5
210
359
4
21.3~22.4
150
248
2
44
210
359
4
22.5
155
253
2
44.5
210
359
4
23
155
253
2
45
210
359
4
23.5
155
276
3
45.5
215
364
4
24
160
281
3
46
215
364
4
24.5
160
281
3
46.5
215
364
4
25
160
281
3
47
215
364
4
25.5
165
286
3
47.5
215
364
4
26
165
286
3
48
220
369
4
26.5
165
286
3
48.5
220
369
4
27
170
291
3
49
220
369
4
27.5
170
291
3
49.5
220
369
4
28
170
291
3
50
220
369
4
28.5
175
296
3
50.5
225
374
4
29
175
296
3
51~53
225
412
5
29.5
175
296
3
54~56
230
417
5
30
175
296
3
57~60
235
422
5
30.5
180
301
3
61~63
240
427
5
31
180
301
3
64~67
245
432
5
31.5
180
301
3
68~71
250
437
5
32
185
334
4
72~75
255
442
5
32.5
185
334
4
76
260
447
5
33
185
334
4
77~80
260
514
6
33.5
185
334
4
81~85
265
519
6
34
190
339
4
86~90
270
524
6
34.5
190
339
4
91~95
275
529
6
35
190
339
4
96~100
280
534
6








Customer Evaluate




Our Company












FAQ


1. Are you manufacturer or trading company?
We are professional manufacturer with more than 10 years experience in this field.

2. How to place an order?
1.Fill your Order List in our online Inquiry System.
2.Directly contact our salesperson by E-mail / Skype / Whats App
We will make a feedback to you ASAP after receive your order list.

3. What is your payment terms?
T/T, Paypal, Western Union, Alibaba assurance for different circumstances.

4. What's your delivery way?
Express delivery, DHL, TNT, FEDEX , EMS, air shipping, sea shipping are available for your request.

5. Do you offer OEM?
Yes, we do. We have laser machine lasering your logo and tool specification on the body of tools. Also, we can print customized on plastic boxes.

6. How about the delivery time?
Usually delivery time is 2~3 days after receiving the advance payment. For the customized product, 7-10 days after receiving the advance payment.
