20w 30w 50w 100 Watts Metal Steel IPG Raycus MAX JPT Mopa Fiber CNC Laser Marker Machine Engraving Marking Etching Machine Price
(Model:PEDB-400D)
Contact:Suki Email:sales32(@)perfectlaser.net
Product Description
Specification
Model No | PEDB-400D |
Type | Standby |
Computer | Includes PC |
IPG Series | Pulsed, High Energy Ytterbium Fiber Lasers |
Central emission wavelength | 1060-1070 nm ,Q-switched operation Output power adjustment range 10%-100% |
Emission Bandwidth (FWHM) | <10 nm |
Long-term average power instability | <5% |
Pulse width, (FWHM) | 100 ns |
Laser switching ON/OFF time | 180 μsec |
Pulse Repetition Rate* kHz | 20-80 kHz |
Energy per pulse (PRR = 20 kHz) | 0.95 mJ |
Typical beam quality, M2 | <1.8 |
Output fiber delivery length | 3m |
Operating voltage | 220V |
Max. Power consumption | 600W |
Net Dimensions | 143*62*101cm |
Net Weight/Gross Weight | 130 kgs/200 kgs |
Scanning Speed | 0-7000mm/s |
Marking Speed | 0-5000mm/s |
Marking size | 110mm×110mm (F-theta 160) |
Spot size | ≤ 40 micron (F-theta 160) |
Cooling unit | Air cooled |
Pilot laser | 650nm diode laser, visible red light for marking guide |
Continuous working time | ≥16h |
