Портативная ленточная пила по дереву машина для резки

Портативная ленточная пила по дереву машина для резки

Категории: Wood Saw Machines >>>
Поставщик: Yantai,Rima,Machinery,Co.,Ltd.

Цена:*

Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики

Product Description

RIMA portable band Mills has designed the RS26 sawmill for budget minded customers looking at getting into milling their own lumber at an exceptional price point. Based on our very popular RS26 model, the RS31 offers hobby sawyers an easy to use, well engineered sawmill with the ability to mill logs up to 31" in diameter and 110" (2.79m) in length. The RS26/31 also supports an unlimited ability to extend your track to handle milling logs of any length

Technology

RIMA portable sawmill designed the RS26 sawmill for budget minded customers looking at getting into milling their own lumber at an exceptional price point. Based on our very popular RS26 model, the RS31 offers hobby sawyers an economical and well engineered mill. Featuring a powder coated structure and a 7.0 HP Kohler gas/petrol engine, this mill is a good choice for hobby sawyers.

Model	RS22G	RS26G	RS31G	RS22E	RS26E	RS31E
Power	Gasoline 7HP (LIFAN, Manual start)	Gasoline 9HP (LIFAN, Manual start)	Gasoline 15HP (LIFAN, Manual start)	Electric Motor 5.5KW		Electric Motor 7.5KW
Displacement	212cc	301cc	420cc	400V 50HZ 3phase
Cutting capacity	559155 2794mm (22”6”110”)	6601782794mm (26”7”110”)	7901782794mm (31”7”110”)	5591552794mm (22”6”110”)	6601782794mm (26”7”110”)	7901782794mm (31”7”110”)
Frame	2pcs	4pcs	4pcs	2pcs	4pcs	4pcs
Blade size	3251340.9mm (128”1-1/4”0.035”)	3670340.9mm (144”1-1/4”0.035”)	3670340.9mm (144”1-1/4”0.035”)	3251340.9 mm (128”1.25”0.035”)	3670340.9 mm (144”1.25”0.035”)	3670340.9mm (144”1-1/4”0.035”)
Safe cutting Speed	13-15s/m			13-15s/m
Blade speed	17m/min			17m/min
Distance teeth	22mm (0.86”)			22mm (0.86”)
Blade Wheel Dia.	475 mm (18.7”)			475 mm (18.7”)
Dimension	406417781800mm (160”70”71”)			406417781800mm (160”70”71”)
Track size	4042x900mm(159”x35.4”)			4042x900mm(159”x35.4”)
Packing	P1: 1800550810mm, P2: 200014095mm			P1: 1800550810mm, P2: 200014095mm
Weight	312/344kg			352/380kg
20”/40”HC	39pcs/78pcs			39pcs/71pcs

Detailed Images

General Construction All major steel components feature either a powder coated or galvanized steel finish. This ensures your mill will stand up to nature's elements. We recommend covering your mill when not in use, but if you forget, it's good to know the mill will endure nature. The head moves up and down along galvanized steel channel via a very easy to turn hand crank system. The blade is kept lubricated by utilizing a water drip system. This prevents sap from gumming up your blade.
	Cutting The mill is capable of cutting 22″ (55cm) diameter logs up to 10' 4" (3.1m) long. Extra track sections are available in 6' 5" (1.95m) increments. Capable of squaring cants at 16″ (40cm) or live edge boards at 18″ (45cm) wide. It can also skim veneers at as thin as 1/16″ (1.6mm). The HM122 will cut within 1″ (25mm) of the deck ensuring that you maximize your usable board foot output.
Power Our mills are powered by a 7.0 HP 4-cycle LIFAN(Kohler, B&S) gas/petrol engine. It features a slant cylinder design, with a cast iron cylinder bore and overhead valve for easy access. The Quad-Clean 4-stage air filtration system ensures only clean air enters the engine for maximum power and life of the engine. In addition, this engine is backed by a 3 year commercial warranty. Attached to the engine is an industrial centrifugal clutch system which offers "gas and go" efficiency and ease.
	Track System The head of our sawmill rolls along rigid 2.5″ x 2.5″ (6cm x 6cm) "L" channel which is cross supported with heavy duty 2 3/8″ x 4 3/4″ (6cm x 12cm) rectangle log bunks. These heavy duty cross supports also provide additional rigidity to the track system. The track also features one easy to use adjustable log clamp to securely hold the log while milling. The track itself consists of two 6' 5" (1.95m) sections allowing for 10' 5" (3.1m) log lengths. Additional 6' 5" (1.95m) tracks may be attached to accommodate logs of any length.
