Product Description
Glass Aluminum Curtain Wall with System Design Fabrication Exterior Double Glazed Glazing Facade Panel Building Envelope
The aluminium glass curtain wall are typically designed with extruded aluminum framing members, although the first curtain walls were made with steel frames. The aluminum frame is typically infilled with glass, which provides an architecturally pleasing building, as well as benefits such as daylighting.

REXI has a long and reputable history beginning as a curtain wall manufacturer in the 2005 to a company today with operations in China and different countries around the world. REXI has set a high standard in high quality, high performance curtain wall design. With over decades of experiences in the facade industry, REXI has a wealth of knowledge and resources to develop class leading curtain wall systems. All of the curtain wall systems used in our designs are exclusive to REXI. We continually develop new systems to meet the ever changing and challenging specifications and green star requirements. Together with virtual trials and testing, engineering and real world testing, REXI can develop a facade system to meet any buildings requirements.
PRODUCT FEATURES
Excellent Thermal Efficient - system U-value low to 0.8 W/㎡.K

Overall curtain wall thermal performance is a function of the glazing infill panel, the frame, construction behind opaque (spandrel and column cover) areas, and the perimeter details. REXI have specially designed curtain wall system. The system thermal insulation U-value is low to 0.8 W/㎡.K
Strong Moisture Protection water penetration resistance high to 1000 Pa
Curtain walls have the primary purpose of keeping air and water out of the building, essentially acting as both a buffer and an insulator. Unlike iscontinuous windows, which are smaller units and can rely to a high degree on sill flashings to capture frame corner leakage, curtain walls cover large expanses of wall without sill flashings at each glazed opening. REXI specially patented curtain wall system water penetration resistance high to 1000 Pa.
Unique Visual Appearance - thorough design and precise fabrication

REXI has strong design team which can make the thorough calculation and precise fabrication, which offer a wide variety of aesthetic variations allowing architects to use any combination of finishes, infills, external feature caps and glazing specification
SYSTEM ACHIEVEMENTS

• Energy Efficiency U-value low to 0.8 W/㎡.K
• Water Penetration Resistance high to 1000 Pa
• Durable powder coating warranty to 20 years
• Glazing unit weight max to 1,000 kg
• Glazing thickness from 4mm to 60 mm
• Sound Resistance Rw to 68 dB
QUICK DETAILS
Types
Unitized curtain wall, Stick curtain wall, Spider curtian wall
Materials
Aluminium alloy and glass/ Aluminum panel/ ACP/ Stone
Hardware
Chinese top brand/ Germany brand
Glass Types
Tempered, Laminated, Double Glazed, Ceramic Fritted
Surface Treatments
PVDF, Powder Coated, Anodized, Electrophoresis, Wooden Grain etc.
Aluminium Alloy
6063-T5/T6, 6061-T5 profile
Advantages
Professional Design Team/ 21,000 square meters large work shop/ International Standards
Standards
In complianca with US BS AU EU standards
Application
Residential Houses & apartments, Commercial Buildings, Skyscrapers etc.
Supply Ability
20,000 square meters per Month
Packing
Plastic Film, EPE Cloth, Wood Case, Steel stillage
Loading Port
QingDao
Company Profile
REXI Industries is a professional leader in design, fabrication and installation of windows, doors and curtain walls. Here at REXI we have full commitment from concept through to completion delivering the project on time and budget. Our designs are roduced using tried and proven details developed by our own engineers. We will work with you to find the right system to meet your design's aesthetics and performance.
FABRICATION CAPACITIES
Proudly we have one of the largest fabrication workshop in North China which covers 21,000 square meters with over 100 experienced workers. We have the big enough capacity for the large scale project.
Products Types
Lines Qty
Annual Production Capacity
Unitized Curtain Wall
4
200,000 sqm
Stick Curtain Wall
4
300,000 sqm
Aluminium Windows & Doors
6
300,000 sqm
QUALITY CONTROL
DESIGN QUALITY CONTROL PROCESSES
QUALITY CONTROL OF SPECIFIC OPERATIONAL PROCEDURES
MATERIAL QUALITY CONTROL PROCESS AT SITE
ALUMINUM PROFILES INCOMING INSPECTION
MACHINING QUALITY CONTROL
ASSEMBLY QUALITY CONTROL
STRUCTURAL SILICONE QUALITY CONTROL
PACKING & SHIPMENT
