Model | GS-005 Good Quality Laboratory Bench top Organic Glass Inert Gas Protection Clear Vacuum Acrylic Glove Box for Experiment |
Material | PMMA |
Product Name | Acrylic glove box or inert gas glove box |
Thickness(mm) | 10mm |
Open door dia.(mm) | 350*350mm |
Operation chamber size(mm) | 900*500*500 |
Sealing property | More than 24 hours |
Model | Operate chamber size(mm) | Acrylic thickness(mm) | Transmission box size(mm) | Raw Material | ||||||||||
A Type | B Type | A type | B type | A type | B type | |||||||||
GS-001 | 1200x800x700 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-002 | 1100x650x600 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-003 | 1000x750x700 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-004 | 900x600x700 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-005 | 900x500x500 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-006 | 800x550x600 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-007 | 700x450x550 | 6-10 | 10 | NONE | 240x240x240 | PMMA | ||||||||
GS-008 | 300x400x500 | 6-10 | NONE | NONE | NONE | PMMA | ||||||||
A type and B type difference: A type have ONLY operation chamber, NO transition chamber. B type have BOTH operation chamber and transition chamber. |
Vacuum Degree for transition box | 0~ -0.1Mpa (2.5 vacuum gauge), pressure maintain period for 12 hrs above | ||||
Vacuum Degree for operation box | 0~ -0.1Mpa (2.5 vacuum gauge), pressure maintain period for 12 hrs above | ||||
Inlet gas type suggested | Argon / Nitrogen / Ammonia gas (with 99.95% purity above) |
1. Q: What's the material of your glove box?
A: We have two types glove box, one made from acrylic and another from stainless steel. This one is made from acrylic material.
2. Q: Different material glove box application for?
A: The different type glove box also used for different environment, acrylic material belongs to high polymer material, acrylic glove box is whole transparent and can't be used for corrosion environment. While stainless steel material glove box only the visual window is transparent and can be used for corrosion environment, like Lithium battery disassembling experiment, electrolyte liquid test etc.
3. Q: How is the max vacuum of acrylic glove box can control?
A: Acrylic glove box the max after pump vacuum can reach 0.1 Mpa.
4. Q: Can i put the balance into the glove box?
A: Yes, just according to your balance size and we can recommend suitable model for you.
5. Q: Do you have MOQ request?
A: MOQ as 1 set.
6. Q: What are the payment terms?
A: You can pay through Alibaba, T/T, Western Union, Master Card, PayPal, etc.
7. Q: What are the shipping methods?
A: You can choose shipping by air, by sea or by Express door to door.
8. Q: How many days can you deliver?
A: Within 15 workdays after we get the payment.
