Hardware

RAM

2G (1GB optional)

ROM

16G  (8GB optional)

LCD Display

5”, 1280*720; Optional protection screen glass

Dimension

175(L)*78(W)*27(H)mm

Touch Panel

Capacitive panel, multi-point touch, G+G

Camera

Rear: 8.0M

Battery

DC 3.7V/4000mAh

RFID

NFC, 13.56MHz smart card

G-sensor

Gravity acceleration sensor

GPS

Support for A-GPS

MIC

Built-in microphone

Speaker

Built-in stereo speaker 8Ω/1.5W

SIM Card

Support 1 SIM card

TF

1x mini SD card up to 32G

Earphones

3.5mm stereo phone jack

Operating Temperature Range

-20℃ to + 70℃

Certification

CE, IP65, ISO9001, GSM TAC certificated

Operating Humidity

0-95%

Barcode

Optional 1D/2D, PDF417 scanner

Antistatic Ability

IEC64000-4-2 standard 15KV

OTA

Support (Can update firmware & app remotely via OTA function)

Package Accessories

Device bag, Screw driver, adapter, USB cable

Extra Support

Launcher APP for free (Only allow to use the specific app, user cannot access other settings/apps on devices)

Free SDK:

Android SDK, Cordova SDK, Windows Web-based SDK etc

OMD logo

Can optional wall-mounted metal box

Software

OS

Android 7.0(Android 6.0 for optional)

CPU Professor

Quad-core, 1.5G, Android 7, MTK6737V/CT

SDK

For free, come with sample package

Cloud-based development

Yes, support

Fingerprint Sensor

Image Size

256*360 pixels

Image resolution

508DPI

Gray scale

8-bit (256 levels)

Imaging Area

18.00mm*12.80mm

Standard

Support ANSI378, ISO19794-2

Image Format

WSQ, JPG,BMP, etc.

Communication

Data link

4G(3G version is optional)

Wi-Fi

802.11 b/g/n

USB

Type C with OTG function

Bluetooth

Bluetooth 4.0
