Air Impact Wrench Product Features:

1.Square Drive:1/2", 1"

2.Max.Torque:550,650,680,720,850,1380,2600,3600N.M

3.Free Speed:7000,7500,8000r/m

4.Capacity Bolt Size:M16, M36, M40, M45

5.Air Inlet:1/4"

6.Air Hose:3/8"

7.Air Pressure:0.63 Mpa

8.Air Consumption:113L/Min

9.Pound Structure:Twin Hammer

10.The Sleeve Size:10#,11#,13#,14# 17#,19#,22#,24#

11.Total Length:540 mm

12.Certificate: GS,CE, EMC,ROHS





Air Impact Wrench Features and Functions:



1. Pneumatic wrench, also known as the combination of ratchet wrench and power tool, is mainly a tool that provides high torque output with minimal consumption. 2.It accelerates the rotation of an object with a certain mass through a continuous power source, and then immediately hits the output shaft, thereby obtaining a relatively large torque output.
3.Pneumatic wrenches are widely used in many industries, such as automobile repairs, heavy equipment repairs, product assembly (commonly known as "pulse tools" and designed for precise torque output), major construction projects, installation of wire sleeves, and any other One place where high torque output is needed.
4. Pneumatic wrenches are available in every standard ratchet socket driver size, from small 1/4 "driver tool assembly and disassembly to 3.5".



Note for pneumatic wrench:
1. Pay attention to the position of the reversing switch before operation so as to understand the direction of rotation when operating the intake valve
2. Be sure to ensure the compressed air entering the wrench air motor: clean and dry air with a maximum pressure of 6.0 bar. Otherwise, it may cause dangerous situations such as drive system failure, overspeed, rupture, and wrong output torque.
3. Make sure that all hoses and other connecting devices are correctly sized and installed securely; do not use damaged, worn or aged air hoses and other connecting devices; it is recommended to install an emergency shut-off valve on the gas supply line, and Let others know where it is installed.
4. Before operating the machine, be sure to check whether there is sufficient lubricant in the oil cup. In the absence or absence of lubrication, the wear speed of the air motor blade will be accelerated, resulting in reduced tool performance and increased maintenance work.
5. The posture of the body must be balanced and stable, and the amplitude should not be too large when operating this tool. During the opening and operation of the tool, please prevent and watch out for sudden changes in torque and force during exercise.
6. If the hose is broken or the connection is broken, an appropriate size air safety device can be installed upstream of the hose, and the hose can be used to prevent the hose from swinging without any shut-down inside the hose. .
7. This tool is a torque tool with a reaction force arm. The huge torque generated by the machine is absorbed by the reaction force arm. Therefore, it is necessary to find a sufficient strength support point for the reaction force arm during operation. In consideration of safety, when working on the machine, be sure to stay away from the working range of the reaction arm, otherwise, it may cause huge injuries to people.



Maintenance method of pneumatic wrench:
1. Need the right air supply system. In this way, the product can be used longer and better.
2. Do not arbitrarily remove the parts in the tool. Not only affects safety, but may damage the tool.
3. The tool is faulty, cannot reach the original function, and can no longer be used. Check it immediately.
4. Regularly check, maintain tools, and add lubricant!
5. Use a variety of tools and follow various safety regulations and instructions.



Model	Product Name	Specification	Packing Size(cm)	G.W/N.W (kg)	PCS/CTN
NEAIW-01 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:650 N.M Free Speed:7500 R.P.M Capacity Bolt Size:M16 Air Inlet:1/4"; Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	43.5*23.5*33	/	8
NEAIW-02 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:650 N.M Free Speed:8000 R.P.M Capacity Bolt Size:M16;Air Inlet:1/4" Air Hose:3/8";Air Pressure:0.63 Mpa Air Consumption:113L/Min Pound Structure:Twin Hammer The Sleeve Size:10#,11#,13#,14# 17#,19#,22#,24#	53.5*31*29	/	6
NEAIW-03 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:680 N.M Free Speed:7000 R.P.M Capacity Bolt Size:M16 Air Inlet:1/4";Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	45*35*33	N.W:2.58	5
NEAIW-04 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:680 N.M Free Speed:7000 R.P.M Capacity Bolt Size:M16 Air Inlet:1/4";Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	43.5*23.5*33	/	8
NEAIW-05 (CE)	Air Impact Wrench	Square Drive:1/2"; Max.Torque:720 N.M Free Speed:7000 R.P.M Capacity Bolt Size:M18 Air Inlet:1/4"; Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer The Sleeve Size:10#,11#,13#,14# 17#,19#,22#,24#	53.5*31*29	3/2.68	6
NEAIW-06 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:720 N.M Free Speed:7000 R.P.M Capacity Bolt Size:M18 Air Inlet:1/4"; Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	43.5*23.5*33	3/2.68	8
NEAIW-07 (CE)	Air Impact Wrench	Square Drive:1/2";Max.Torque:850 N.M Free Speed:8000 R.P.M Capacity Bolt Size:M18 Air Inlet:1/4"; Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer The Sleeve Size:10#,11#,13#,14# 17#,19#,22#,24#	53.5*31*29	/	6
NEAIW-08 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:850 N.M Free Speed:8000 R.P.M Capacity Bolt Size:M18 Air Inlet:1/4"; Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	43.5*23.5*33	/	8
NEAIW-09 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:640 N.M Free Speed:7000 R.P.M Capacity Bolt Size:M16 Air Inlet:1/4"; Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	45*35*33	N.W:2.58	5
NEAIW-10 (CE)	Air Impact Wrench	Square Drive:1/2" Max.Torque:640 N.M Free Speed:7000 R.P.M Capacity Bolt Size:M16 Air Inlet:1/4";Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	43.5*23.5*33	N.W:2.58	8
NEAIW-11 (CE)	Air Impact Wrench	Square Drive:1/2" Or 3/8" Max.Torque:550 N.M Free Speed:9000 R.P.M Capacity Bolt Size:M14 Air Inlet:1/4";Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	54*26*24		10
NEAIW-12 (CE)	Air Impact Wrench	Square Drive:1/2" Or 3/8" Max.Torque:550 N.M Free Speed:9000 R.P.M Capacity Bolt Size:M14 Air Inlet:1/4";Air Hose:3/8" Air Consumption:113L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer The Sleeve Size:14#,15#,16#,17#,19#,21#	57*35*26		10
NEAIW-13 (CE)	Air Impact Wrench	Square Drive:3/4" Max.Torque:1380 N.M Free Speed:6500 R.P.M Capacity Bolt Size:M21 Air Inlet:3/8";Air Hose:1/2" Air Consumption:226 L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	48.5*29.5*26	N.W:4.6	5
NEAIW-14 (CE)	Air Impact Wrench	Square Drive:3/4" Max.Torque:1380 N.M Free Speed:6500 R.P.M Capacity Bolt Size:M21 Air Inlet:3/8"; Air Hose:1/2" Air Consumption:226 L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer The Sleeve Size:32mm, 36mm	48.5*29.5*26	N.W:4.6	5
NEAIW-15 (CE)	Air Impact Wrench	Square Drive:3/4" Max.Torque:1800 N.M Free Speed:4300 R.P.M Capacity Bolt Size:M36 Air Inlet:3/8"; Air Hose:1/2" Air Consumption:236 L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	35*33.5*33	N.W:7.3	2
NEAIW-16 (CE)	Air Impact Wrench	Square Drive:1" Max.Torque:1800 N.M Free Speed:4300 R.P.M Capacity Bolt Size:M36 Air Inlet:3/8"; Air Hose:1/2" Air Consumption:236 L/Min Air Pressure:0.63 Mpa Pound Structure:Twin Hammer	35*33.5*33	N.W:7.5	2
NEAIW-17 (CE)	Air Impact Wrench	Square Drive:1"; Total Length:540 mm Max.Torque:2600 N.M Free Speed:4000 R.P.M Capacity Bolt Size:M45 Air Inlet:1/2"; Air Hose:1/2" Air Consumption:280L/Min Air Pressure:0.63 Mpa Pound Structure:Pinless Hammer	62.5*23.5*32	14/12.5	2
NEAIW-18 (CE)	Air Impact Wrench	Square Drive:1"; Total Length:540 mm Max.Torque:2400 N.M Free Speed:4000 R.P.M Capacity Bolt Size:M42 Air Inlet:1/2"; Air Hose:1/2" Air Consumption:280L/Min Air Pressure:0.63 Mpa Pound Structure:Pinless Hammer	62.5*23.5*32	13/10.5	2
NEAIW-19 (CE)	Air Impact Wrench	Square Drive:1";Total Length:540mm Max.Torque:2800 N.M Free Speed:4000 R.P.M Capacity Bolt Size:M45 Air Inlet:1/2"; Air Hose:1/2" Air Consumption:280L/Min Air Pressure:0.63 Mpa Pound Structure:Pinless Hammer	62.5*23.5*32	14/12.5	2
NEAIW-20 (CE)	Air Impact Wrench	Square Drive:1";Total Length:615mm Max.Torque:3600 N.M Free Speed:3200 R.P.M Capacity Bolt Size:M45 Air Inlet:1/2"; Air Hose:1/2" Air Consumption:338L/Min Air Pressure:0.63 Mpa Pound Structure:Pinless Hammer	67*23.5*35.5	17.5/16.5	2











If you are interested in our Air Impact Wrench, please don't hesitate to contact us.
