Цены на электрический Мусоровоз, система для отката мусора с шасси
US $20000-$40000
Поделиться:
4x2 isuzu 4-5 cbm compact garbage trucks | ||
Vehicle Parameters | ||
General | Vehicle Model | XDR5040XLCQL6 |
Vehicle Brand | XDR | |
Chassis Brand | isuzu | |
Overall Dimension(mm) | 5995*2020*2980 (mm) | |
GVW/Curb Weight(kg) | 4460/3185 | |
Chassis Parameters | ||
Cab | Cab Seat | 2 |
Air Conditioner | Optional | |
Engine | Fuel Type | diesel |
Engie Model | 4KH1CN6LB | |
Engine Brand | QL | |
Emmission Standard | Euro5 | |
Chassis | Drive Type | 4*2 |
Wheelbase(mm) | 3360 | |
Tyre Specification | 7.00R16 8PR | |
Tyre No.(pcs) | 6 | |
Max Speed(km/h) | 105 | |
Leaf Spring | 3/3+2 | |
Axle Load | 1785/2675 kg | |
F/R Tread | 1504/1525 kg | |
F/R Overhang | 1015 /1620 mm | |
Approach Angle | 24 | |
Departure Angle | 15 | |
Displacement | 2999 |
Superstructure Parameter: | |
Tank Shape |
Arc-shape/Square Optional |
Tank Material thickness |
Bottom:4mm Side:4mm |
Tank Material |
T420(Special Steel) |
Compression Ratio |
≥2.5 |
The effective volume of the bucket |
≥0.8m³ |
