Wholesale Multifunction 180KG Hot Melt Hand Push Road Line Marking Machine
TT-ZCP400 is used for the cold solvent paint, water born paints line marking. and also it can be used for special material painting (two component 98:2) Or (1:1) MMA. The biggest advantage of this model is that it can be installed on the truck to mark lines on the city road, highway road, it is available for small project and big project.
ITEM | PARAMETERS |
Material tank | 400L (Double tank with 2x110L) |
Glass beads tank | 110L |
Engine | HONDA 13 HP gasoline engine |
Marking Line Width | Standard equipped with 150mm |
50/100/150/200/250/300mm (optional) | |
Marking mode | High pressure airless spraying , 2 component 98:2 |
Dimension | 1150x1390x1410mm |
Weight | 735KG |
Paint tank and stirring system
Comparing with others, it has two large paint tank 2X200L, with rolling stirring system. So it is available for long way marking work without any interruption
New developed hydraulic pump High pressure variable hydraulic pump
It replaces complex electric control and hydraulic system, integrate the mechanical, electrical and hydraulic system well.
auto shuttle hydraulic cylinder
This is the most important improvement to keep the machine high quality and long time life time
Microcomputer control system
It makes the operation fully automatically. Also more other extra function available. Meterial dosage test & print, marking length and marking area test & print. Real-time location when executing
OUR FACTORY
OUR TEAM
1.Q:Are you a factory or trading company?
A:We are factory which is dedicated in developing road traffic field more than 20 years.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Nantong City, Cangzhou City and Zhengzhou City. All our clients are warmly welcome to visit us!
3.Q:What’s the marking area for one ton of thermoplastic paint?
A: 200-250 square meters for flat lines, about 150 square meters for convex lines, it depends on two factors: line thickness and road surface flatness.
4.Q:How many glass beads drop on type for one ton of thermopalstic paint?
A: About 100KG for one ton thermoplastic paint.
6.Q:How many worker is necessary for one marking team?
A: 6-8 worker
A:We are factory which is dedicated in developing road traffic field more than 20 years.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Nantong City, Cangzhou City and Zhengzhou City. All our clients are warmly welcome to visit us!
3.Q:What’s the marking area for one ton of thermoplastic paint?
A: 200-250 square meters for flat lines, about 150 square meters for convex lines, it depends on two factors: line thickness and road surface flatness.
4.Q:How many glass beads drop on type for one ton of thermopalstic paint?
A: About 100KG for one ton thermoplastic paint.
6.Q:How many worker is necessary for one marking team?
A: 6-8 worker
