Type | Geomemebrane | Width | 1m-9m |
Color | white,black,green,blue | Surface | both sides smooth/both sides textured |
Material | HDPE/LDPE/LLDPE/MDPE/EVA/ Virgin or mixted or recycled | Thickness | 0.1mm-4mm |
Length | 50-100-150 m/roll (at Request) | Certificate | CE/ISO9001 |
Item | 0.75mm | 1mm | 1.25mm | 1.5mm | 1.8mm | 2.0mm | 2.5mm | 3.0mm | |||||||
Minimum density(g/cm3) | >=0.94 | >=0.94 | >=0.94 | >=0.94 | >=0.94 | >=0.94 | >=0.94 | >=0.94 | |||||||
Strength at yield ,N/mm | 11 | 15 | 18 | 22 | 27 | 29 | 37 | 44 | |||||||
Strength at break,N/mm | 20 | 27 | 33 | 40 | 53 | 57 | 67 | 80 | |||||||
Elongation at yield,% | 13 | 13 | 13 | 13 | 13 | 13 | 13 | 13 | |||||||
Elongation at break,% | 700min | ||||||||||||||
Tear resistance N | 93 | 125 | 160 | 190 | 219 | 250 | 315 | 375 | |||||||
Puncture resistance N | 240 | 320 | 400 | 480 | 618 | 640 | 800 | 960 | |||||||
Stress crack resistance,hrs | 300 | ||||||||||||||
Carbon black content ,% | 2.0-3.0 | ||||||||||||||
Standard OTI Min | 100 | ||||||||||||||
High pressure OTI Min | 400 | ||||||||||||||
Water vapor permeability (g.cm/cm2,s,Pa) | <=1.0*10-13 | ||||||||||||||
Dimensional Stability(%) | +-2 |
