Green 853D 1A BGA Rework Station 3 in 1 SMD Soldering Iron Stations With DC Power Supply Hot Air Gun Rework Station Soldering
 |  |  |  |  |
 |  |  |  |  |
Special Function:
1.Auto/manual function
2.Iron sleep function
Main function
This mode has all merits of origin YIHUA 853D 1A,and add the follow function
1.Iron handle add to iron sleep function: iron handle have 10mins sleep function.
2.Air gun handle add to auto./manual conversion function ,
Manual mode: air gun back into the handle frame, air gun to maintain the current state of the work, the
manual mode is suitable for frequent use of air guns, eliminating the need for back and forth to cool the
warming process, convenient.
Automatic mode: air gun back into the handle frame, air gun automatic cooling to standby, automatic mode for infrequently used air gun to save energy and reduce wear and tear on the machine, to extend the life of the machine.
This new type add to 5V output USB interface ,it more convenience repair mobile phone,also canuse power supply for mobile.
all parts is LED digital display ,and the current is 4 digital precise display current value,the
current value can precise display mA value.it is very directly perceived through the senses.
The goods inside board use double panel SMT technology,the performance more stability and
durable.
Wiring terminal output use thick material than before,then the output end power will be larger
than before.
The iron holder is more professional and convenience ,the iron holder include solder tips flux
and cleaner tips copper wire ball,more convenience clean tips,it's prolong use life.
Technical Data
1.Auto/manual function
2.Iron sleep function
Main function
This mode has all merits of origin YIHUA 853D 1A,and add the follow function
1.Iron handle add to iron sleep function: iron handle have 10mins sleep function.
2.Air gun handle add to auto./manual conversion function ,
Manual mode: air gun back into the handle frame, air gun to maintain the current state of the work, the
manual mode is suitable for frequent use of air guns, eliminating the need for back and forth to cool the
warming process, convenient.
Automatic mode: air gun back into the handle frame, air gun automatic cooling to standby, automatic mode for infrequently used air gun to save energy and reduce wear and tear on the machine, to extend the life of the machine.
This new type add to 5V output USB interface ,it more convenience repair mobile phone,also canuse power supply for mobile.
all parts is LED digital display ,and the current is 4 digital precise display current value,the
current value can precise display mA value.it is very directly perceived through the senses.
The goods inside board use double panel SMT technology,the performance more stability and
durable.
Wiring terminal output use thick material than before,then the output end power will be larger
than before.
The iron holder is more professional and convenience ,the iron holder include solder tips flux
and cleaner tips copper wire ball,more convenience clean tips,it's prolong use life.
Technical Data
| Rated voltage | AC 220V±10% 50HZ ( 110V±10% 50HZ) |
| Total Power | 720W |
| Work Environment | 0-50°C |
| Gun Work Voltage: | AC:220V±10% 50HZ( 110V±10% 50HZ) |
| Gun Output Power | 650W±10% |
| Gun Temperature Range | 100°C-480°C |
| Temperature Stability | ±2°C |
| The air volume | 120L/min |
| Iron Work Voltage | AC:26V±10% 50HZ |
Iron Output power | 50W±10% |
| Iron Temperature range | 200°C-480°C |
| Iron Temperature stability | ±2°C |
| Tip of ground impedance | <2ohm |
| Tip of ground voltage | <2mV |
| DC power supply parts | |
| Work Voltage | AC 20V±10% 50HZ ( 110V±10% 50HZ) |
| Output Power | 15W |
| Output Voltage | 0-15V |
| Output Current | 1A |
| Load Stability | <0.01±2mv |
| Recovery Time | <100us |
| Temperature coefficient | <300PPm/°C |
| Protection starting current | >standard value 10% |
Ripple dB<1mvrms (virtual value)
 |  |  |  |
| Apollo Soldering Tip | Wood Burning Tip | LT Series | 900M-T-IS |
 |  |  |  |
| Unix Series Soldering Tip | T18 Series | TS100 Series | 900M-T Series |
