Powerful 10L Agricultural Quadcopter Drone



1. Description

Drones are becoming a critical tool for farmers. Many farmers are already benefitting from drone (UAV) technology.



 Precision Agriculture  or  smart farming  is based on the use of advanced technology in the management of crops to increase output without compromising quality. The need to maintain the balance between cost and quality has made drones particularly attractive for smart farming. Drones are affordable and don’t require a whole lot of training to pilot.



In Agriculture, an important use for drones is watering. Users can use Powerful 10L Agricultural Quadcopter Drone to water the crops. It's high efficiency , irrigation uniformity  than artificial irrigation.



2. Parameter

Wheelbase (mm)	1450mm(mm)
Specification (mm)	Expand: 1016×1026mm×558mm(without propeller)
Operating voltage	24v(12s) (2x16000mah)
Weight (excluding battery)	13kg
8210 motor	100kv 4ps
Load	10L
Wind resistance coefficient	Class 6 - 7 winds
Propeller	30 inches
Flight speed	0-10m/s
Spray amplitude	4-5m
Maximum takeoff weight	>23kg
Effective Load/Flight time	Flight time 8KG/15min;4—5KG/22-25min
Ground control system	Pc
Flight control system	K++
Dotter power system	Tu-10010 Electric adjustment: 80a
Sprinkler system	Pressure sprinkler system, 4 pressure sprinklers
Maximum pressure	5mpa
Spraying flow	0.8 5.0L/min adjustable (with pressure cone nozzle)
Operating efficiency	6.6km² / time
Characteristic function	Microwave fixed-height radar, fixed-height and stable, supporting ground-like flight
	Android mobile phone ground station, easy to use / PC ground station, full voice
	Broadcast data real-time display, voice broadcast, flight status control at any time
	To support route planning, fully autonomous flight operations
	To support AB point operations
	Support key take-off, landing, without manual intervention, improve the safety of
	Ceramic nozzles, spraying speed can be adjusted, spraying uniform
	Continuous spray at break point, drug-free, low-power return
	Drug quantity detection, can set no medicine automatic record breakpoint return
	Electricity detection, can set low power automatic record breakpoint return
	To support irregular block route planning, up to 340 flight points
	Support setting obstacle points, Planning routes to avoid obstacle areas
	Support setting alternate landing points. Convenient for large parcel jobs to reserve
	RTK interface to support upgrading and installation of RTK





Remarks: If you have special requirement, send us online message or inquiry, we can customize for you.





3. Configuration list

Flight control*1pc

Remore control*1pc

Battery(12S-16000mAh)*2pcs

Charger*1pc

Drone arms(40*36*475mm)*4pcs

Fogger arms(20*16*150)*4pcs

Pressure sprinkler*4pcs

Holder*1pc

Top carbon board*1pc

Middle carbon board*1pc

Bottom carbon board*1pc

PCBA*1pc

Outside case*1pc

Spray tank*1pc

Water pump*1pc



4. Our Company





5. FAQ

1. What is the leadtime and MOQ of Powerful 10L Agricultural Quadcopter Drone?
    MOQ is 1pc, and we usually can delivery it within 10 days. For more information, contact us please.

2. How can I buy  Powerful 10L Agricultural Quadcopter Drone?
    1st, let us know your purchase quantity and requirement.
    2nd, we will quote according to your quantity and requirement.
    3rd, profoma Invoice will be sent to you, after we receive your payment, we will strart production.
    4th, aftter we deliver the instrument, we will provide you shipping tracking number.

3. What's the warranty of Powerful 10L Agricultural Quadcopter Drone?

    Each instrument comes with differenty warranty, contact us, please.



4. What type of payment can I arrange?

    You can pay via Alibaba, Western Union or bank transfer.



5. Where is your company based?
    Our office is in Shenzhen, China. Welcome to visit us.
