Products Description
Y series motors are totally enclosed and fan cooled(TFEC).Three-phase squirrel cage induction motors. They are newly designed in conformity with the relevant requirements oi IEC standards. Y series motors have outstanding performance, such as high efficiency, energy-saving, high starting torque, low noise, little vibration, reliable operation and easy maintenance, etc.
Y series motors are widely used in many places, where do exist combustible, explosive or corrosive, and with any special requirements, such as drilling machines, pumps, fans, mixer, transport machines, food machines agriculture machines and equipments , etc.
Y series motors are widely used in many places, where do exist combustible, explosive or corrosive, and with any special requirements, such as drilling machines, pumps, fans, mixer, transport machines, food machines agriculture machines and equipments , etc.
OPERATING CONDITIONS： | ||
Ambient temperating： | -15℃≤0≤40℃ | |
Attitude： | Not exceeding 1000 meters | |
Rated voltage: | 380V±5% | |
Rated frequency: | 50HZ/60HZ | |
Connection: | Y Start-Connection for 3kw and below △ Date-Connection for 3kw or more | |
Insulation Class: | Class B/ Class F | |
Protection class: | Continuous (S1) | |
Duty/Rating: | IP54 | |
Cooling type: | IC0141 | |
