Products Description

Y2 Series motors are totally enclosed fan cooled(TEFC).squirrel cage three-phase induction motors,developed with new technique They are renewal and upgrading products of Y series The mounting dimension is fully conformed with IEC standard .
The motors have the merits of beautiful modeling .compact structure ,low noise,high efficiency,large staring torque,easy serving,etc The motors are adopted with F class insulation and designed with assessing method for insulation practice.it enhances greatly motor's safety and reliability.These motors have reached an international advanced level Y2 series motors can be widely used in various machines and equipments.such as drilling machines,blowers ,pumps, compressors,transporters,agricultural and food processing machines

OPERATING CONDITIONS：
Ambient temperating：	-15℃≤0≤40℃
Attitude：	Not exceeding 1000 meters
Rated voltage:	380V±5%
Rated frequency:	50HZ/60HZ
Connection:	Y Start-Connection for 3kw and below △ Date-Connection for 3kw or more
Insulation Class:	Class B/ Class F
Protection class:	Continuous (S1)
Duty/Rating:	IP54
Cooling type:	IC0141
