Гибридный солнечный контроллер заряда 1600 Вт mppt инвертор умный немодулированного синусоидального сигнала
- Категории: Solar Energy Products >>>
- Поставщик: Guangdong,Techfine,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Overview
Products Description
Product Parameter
Model | 1000VA | 1500VA | 2000VA | 3000VA | 5000VA | ||||
Input Voltage(DC) | 12V/24V | 12V/24V | 12V/24V | 24V/48V | 24V/48V | ||||
Nominal Voltage | 220VAC(Standard) | ||||||||
Rated Power | 800W | 1200W | 1600W | 2400W | 4000W | ||||
Waveform | Pure Sine Wave | ||||||||
Battery Type | VRLA / GEL /GEL DEEP CYCLE/LITHIUM | ||||||||
Maximum pv array power | 12V:800W / 24V:1600W/ 48V:3200W | ||||||||
PV Input Voltage Range (PWM Controller) | 12V:MPPT 15V-150VDC / PWM 15V-30VDC | ||||||||
24V:MPPT 30V-150VDC / PWM 30V-60VDC | |||||||||
48V:MPPT 60V-150VDC / PWM 60V-105VDC | |||||||||
Maximum solar charging current | 60A | ||||||||
Maximum AC charging current | 15A/8A | 30A/15A | 40A/20A | 30A/15A | 42A/21A | ||||
Transfer Time | <10ms(UPS mode)/<20ms (INV mode) | ||||||||
Load peak ratio | (MAX)3:1 | ||||||||
Static power(W) | 5W | 11.5W | 13W | 15W | 20W | ||||
Protections | Power supply: Input overcurrent protector | ||||||||
WHAT CAN WE OFFER YOU
Factory Tour
FAQ
Q1: Why you should choose us?
---More than 20 years Electrical Equipment factory experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 1-2years warranty and 1% sapre parts for free
---We will repair the PCB or provide new one
Q3: What kind of certification you have?
---ISO9001,ISO14001, CE,ROHS,UL,and so on
---All series product pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days;
Q5. Can I have a sample order?
---Yes, we welcome sample order to test and check quality.
Q6. Do you have any MOQ?
---Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ,1 pc
for sample checking is available.
Q7. Do you support OEM?
---Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
---More than 20 years Electrical Equipment factory experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 1-2years warranty and 1% sapre parts for free
---We will repair the PCB or provide new one
Q3: What kind of certification you have?
---ISO9001,ISO14001, CE,ROHS,UL,and so on
---All series product pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days;
Q5. Can I have a sample order?
---Yes, we welcome sample order to test and check quality.
Q6. Do you have any MOQ?
---Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ,1 pc
for sample checking is available.
Q7. Do you support OEM?
---Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
