Compatible with most of the thermal plates and developers available on the market.
Maximun resolution for the reproduction of stochastic screens
Fast ink-water balance.
Enhanced constrast and stability.
Runs more than 100.000 impresions without baking.
Cost-efective.
CTP-A plate meets user's needs and optimize the printing perfomance.
Technical Characteristics
Thermal positive plate to operate in CTP systems with infrared (IR) laser diode between 800-850 nm.
No pre-heat required.
Anodized non-image area. Exposure / Coating
Coating colour: blue
intense Contrast after development: very high
Day light sensitivity: up to 2 hours exposure does not affect the plate
Spectral sensitivity: 800-850 nm.
Peak sensitivity at 830 nm.
Compatible with most of the thermal platesetters: Creo, Heidelberg, Screen, Lüscher, etc...
Required energy: 120-130 mj/cm2
Image reproduction: 1-99 % at 250 lines per inch and FM screening Development Use developer Revelith-CTP at 23oC ± 1ºC Compatible with most of the thermal plate developers on the market
Development time: 30 seconds ± 5 seconds
Replenishment: with the same developer at 120-140 ml/m2
Gumming Use Gomalux-LP When hardened by baking,apply Quemagum-LP
Deletion: Use deletion pens
Dualpoint-LP Baking
Hardening the coating by baking enables very long runs, over 500.000 impressions, depending on press conditions.
Apply Quemagum-LP Baking conditions: Static oven: 200-230°C during 5-6 minutes
