Стабильно качественная машина для воздушно-плазменной резки

Описание и отзывы

Характеристики

Inverter DC Air Plasma Cutter
Model	CUT-100	CUT-120	CUT-160	CUT-200
Type	IGBT Module
Rated input voltage (V)	three phase AC380 ±15%
Rated frequency (Hz)	50/60
Rated input capacity (KVA)	15	18	30	41
Rated input current (A)	23	27	45	62
No-load voltage (V)	380	280	380	380
Output current (A)	30-100	30-120	40-160	40-200
Rated working voltage (V)	120	128	144	160
Duty cycle (%)	60	60	60	60
No-load loss (W)	100	100	100	100
Efficiency (%)	85	85	85	85
Power factor	0.93	0.93	0.93	0.93
Net weight (KG)	40.3	40.3	56.9	59
Gross weight (KG)	48.2	48.6	74	77
Packing	carton	carton	wooden	wooden
Dimension of machine (mm)	645×335×576	645×335×576	700×360×638	700×360×638
Dimension of packing (mm)	700×390×660	700×390×660	760×450×735	760×450×735
Method of arc start	uncontact	uncontact	uncontact	uncontact
	steel: 1-30	steel: 1-35	steel: 1-40	steel: 1-60
Optimum thickness of work piece (mm)	steel: 1-25	steel: 1-30	steel: 1-35	steel: 1-50
	aluminum/copper: 1-12	aluminum/copper: 1-15	aluminum/copper: 1-17	aluminum/copper: 1-25
including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, pressure regulator×1pcs, gas hose×0.6meter, hose hoop×2pcs, cutting torch×1pcs
