Токарный станок с ЧПУ VMC
US $9600-$10000
4-осевой 5-осевой фрезерный станок с ЧПУ VMC1050 тайваньским шпинделем и PMI/HIWIN линейной
- Категории: Machine Centre & Parts >>>
- Поставщик: LIAOCHENG,DONGYUAN,MATERIALS,INDUSTRY,CO.,LTD
Поделиться:
Описание и отзывы
Характеристики
Product Description
Item | Specification | Unit | |||
VMC1050 |
| ||||
workbench | size | 1200×420 | mm | ||
Max. load | 400 | kg | |||
T-slot size | 5-18-80 | Mm/each | |||
Processing range | Max. travel X axis (workbench) | 1000 | mm | ||
Max. travel Y axis (slide carriage) | 450 | mm | |||
Max. travel Z axis (main shaft) | 550 | mm | |||
Spindle nose to workbench surface | Max. | 650 | mm | ||
Min. | 100 | mm | |||
Spindle center to Z axis guiderail | 575 | mm | |||
spindle | Taper (7:24) | BT 40 φ150 |
| ||
Speed range | 8000 | r/min | |||
Motor power | 5.5 | kw | |||
feed | Rapid traverse | X axis | 12 | m/min | |
Y axis | 12 | ||||
Z axis | 8 | ||||
speed | 1-10000 | mm/min | |||
Magazine | Type | disc |
| ||
capacity | 24 | pcs | |||
Tool change time | 2.5 | s | |||
Positioning accuracy | Accuracy standard | JISB6336-4:2000/ GB/T18400.4-2010 |
| ||
X/Y/Z axis | ±0.008 | mm | |||
Repeatability accuracy X/Y/Z axis | ±0.005 | mm | |||
Machine dimension (L*W*H) | 3000×2200×2600 | mm | |||
Approx. weight | 5500 | kg | |||
1. Graphitic cast iron for major components like the bed, workbench, slide block, stand column and spindle box, 2 aging treatment for stress relief, enabling good performance in stability and rigidity and ensuring high accuracy of the machine even after long-time service.
2. Well-known brand spindle unit with high speed, high accuracy and high rigidity, reinforced treatment for all important parts, assembling and calibration of the entire spindle unit under constant temperature, computerized machine calibration and commissioning, enabling the entire spindle unit with long service life and high stability.
3. Disc type automatic magazine tool with capacity of 16/24 tool, ensuring accurate tool change and short change time and improving the processing efficiency.
Packaging & Shipping
Our Services
ØHighly compatible system design: compatible with mainstream cnc controllers like GSK, KND, SIMENS, FANUC and WASHING etc.
ØHigh productivity and efficiency: full automatic operation mode to save labor cost, minimize manual manipulation and increase production efficiency
ØReliable and stable product quality: over 10 years of experience in machine R&D and manufacturing ensuring you stable and smooth operation of the machine
ØMultifunction purpose: can be used to process various workpiece with the function to drill, cut, threading and milling etc.
ØCustomized design and configuration: we can design and manufacture customized machine products according to client particular requirement.
Attentive service: on-line and on-site support service available with our technicians and engineers
Company Information
