4 ports kvm switch hdmi 3840*2160@60Hz 4:4:4 USB2.0 L/R audio output for home theatre
Product Description
This 4x1 HDMI KVM Switch provides you with great flexibility in integrating cross-platform computer equipment easily. It makes you available to switch easily and reliably between any HDMI computers using one HDMI compliant display.
The 4x1 HDMI KVM Switch supports USB 2.0 hub and USB 2.0 keyboard /mouse. By using USB 2.0 hub ports on the KVM, you even can attach USB drive, printer, barcode scanner or other USB devices to the KVM. Switching can be controlled through variable methods, such as the front panel source selector buttons, IR signals and hot keys on keyboard. With EDID emulators in every input ports, keep PCs always have correct display information, prevent display settings changed while switching input ports. Support L/R audio output.
Features
1. Using only 1 set of keyboard, mouse and monitor to control 4 computers
2. Available to use keyboard without any delay after switching input source
3. Support hot key commands and mouse gesture to switch inputs
4. Support resolution up to 3840*2160@60Hz 4:4:4
5. Complaint with HDCP 2.2
6. Support USB2.0 for printers, USB drives, etc
7. With EDID emulators in each input port, keep PCs always having correct display information
8. Support front panel buttons, IR signals, keyboard hot keys to control KVM switch
9. Support Unix/ Windows/ Debian/ Ubuntu/ Fedora/ Mac OS X/ Raspbian/ Ubuntu for Raspberry Pi and other Linux based systems
10. Support auto switching among all devices so as to monitor the devices in a specified time interval
11.Support hot plug, connect or disconnect devices to the KVM switch at any time without turning off devices
12. Support analog L/R audio output
13. Support HDR 10 and Vision
Specification
HKS0401A1U | 4x1 HDMI KVM Switch | |
Functionality: | ||
Auto Scan | Yes | |
Port selection | Front panel buttons | Yes |
Keyboard hotkeys | Yes | |
IR remote control | Yes | |
Console commands | No | |
Technical: | ||
Resolution | Up to 3840x2160@60Hz 4:4:4 | |
Auto to get EDID | Yes | |
Data rate | 18 Gbps | |
Auto scan interval | 1~250 Seconds | |
Beep Sound | On/Off | |
OSD | No | |
Supported OS | Unix/Windows/Debian /Ubuntu /Fedora /Mac OS X/ Raspbian /Ubuntu for Raspberry Pi and other Linux based systems | |
Console ports | Keyboard emulation | 1 * USB Type A |
Mouse emulation | 1 * USB Type A | |
USB 2.0 Hub ports | 1 * USB Type A | |
Video /Audio | 1 * HDMI Type A | |
RS232 | NA | |
LAN | NA | |
System ports | USB Data | 4 * USB Type B |
Video / Audio | 4 * HDMI Type A | |
ESD protection | Human body model - ±8kV (Air-gap discharge) | |
Mechanical: | ||
Chasing material | Aluminum Alloy | |
Product dimensions | 300 (L) x 117 (W) x 27 (H) mm | |
Item weight | 800g | |
Company Information
Established in 2013, Tesla Elec Technology Company Limited is a professional manufacturer and exporter that is concerned with the design, development and production of audio and video matrix, splitter, switcher, KVM, extender and converter.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are providing ODM and OEM services in various video related products, just tell us your requirements, we can do more than you can imagine.
