1 Size: 183 * 193 * 100mm
2 Weight: 0.88kg
3 Frequency: 2.4GHz ISM band (2400MHz to 2485MHz)
4 Modulation mode: QPSK
5 Channel bandwidth: 5.0MHz
6 Spread spectrum: DSSS
7 Adjacent channel rejection:> 38dbm
8 Transmitter power: <100mW (PCB testing), <20dbm (3 meter air testing)
9 Operating Current: <105mA
10 Operating Voltage: 7.4 ~ 15V
11 Control distance: more than 900 meters ground, 1.5kms air
12 Channel: 9 channels, 5 ~ 9 channels are customizable
13 Simulator model: under the simulator model the transmitter action turn off, change to power saving model
14 Screen: 2.8 inches 16 colorful screen, 240 * 320 pixels
15 Compatible model: Include all 120 degree and 90 degree swashplate helicopter, all fix wing and glider, five flying model and aircraft
