Product Description
LUYANG CALCIUM SILICATE BOARD
Calcium silicate board products are made of SIO2 and CAO through high temperature and high pressure reaction, adding environmental protection fiber, new energy-saving insulation material without asbestos, the product can be long-term use in 650° high temperature environment, extend the service life of equipment. It is a kind of high efficient energy-saving material with temperature limited 650 cent-degree. Characterised by low bulk density, high specific strength, superior heat resistance, outstanding thermal insulation, excellent durability, chemical corrosion resistance, easy to be cut by saw and easy installation, calcium silicate can be widely used for the insulation of industrial kiln.
1.Small board: 595*595mm /600*600mm /603*603mm /595*1195mm /600*1200mm
2. Big board: 1200*2400mm /1220*2440mm /1220*3050mm
3.Thickness: 4.5, 5, 6, 8, 10, 12, 15, 18, 20, 25mm (3.5-30mm)
2. Big board: 1200*2400mm /1220*2440mm /1220*3050mm
3.Thickness: 4.5, 5, 6, 8, 10, 12, 15, 18, 20, 25mm (3.5-30mm)
Specification
Description | LY-M CALCIUM SILICATE INSULATION BOARD | |||
Maximum Use Temperature (℃ ) | 650 | |||
Chemical Composition (%) | ||||
SiO2 | 37-42 | |||
CaO | 29-34 | |||
Al2O3 | 10-12 | |||
MgO | 1.8-2.1 | |||
Color | White | |||
Density (kg/m³) | 230±10% | |||
Modules of Rupture (MPa) | ≥0.30 | |||
Compressive Strength (MPa) | ≥0.50 | |||
Permanent Linear Shrinkage (%) | 650℃ x16h≤2.0 | |||
Thermal Conductivity (W/m·K) | ||||
100℃ | ≤0.057 | |||
200℃ | ≤0.069 | |||
400℃ | ≤0.098 | |||
Characteristics:
1.Good durability, can bear high temperature within the limit of continuous heat load.
2.Non-deformation within the temperature range.
3.Low thermal conductivity, in the whole range are used with unmatched adiabatic performance.
4.Light weight, high strength. It is the highest in these hard thermal insulation products.
5.Better durability, use for a long time without powder.
6.Construction with ordinary carpenter applicability, tools can be optional cut products.
7.Used safety, hygiene. Excluding asbestos, sulfur, chlorine such poisonous substances.
8.Fear water, but after drying also can be used.
Application:
It is widely used in power plants, petrochemical plants, pipeline systems equipment, as well as heating pipe network system and non-corrosive to stainless steel.
1.Good durability, can bear high temperature within the limit of continuous heat load.
2.Non-deformation within the temperature range.
3.Low thermal conductivity, in the whole range are used with unmatched adiabatic performance.
4.Light weight, high strength. It is the highest in these hard thermal insulation products.
5.Better durability, use for a long time without powder.
6.Construction with ordinary carpenter applicability, tools can be optional cut products.
7.Used safety, hygiene. Excluding asbestos, sulfur, chlorine such poisonous substances.
8.Fear water, but after drying also can be used.
Application:
It is widely used in power plants, petrochemical plants, pipeline systems equipment, as well as heating pipe network system and non-corrosive to stainless steel.
Packing & Delivery
Package: inner plastic bags,outer cartons and pallet with heat shrinkable film.
We also supply OEM service, the package can be designed according to your requirements.
Shipping: By vessel or by train from any Chinese port, Samples can be delivered by International express.
Shipping: By vessel or by train from any Chinese port, Samples can be delivered by International express.
Our service
1. Strict QC & Fast delivery.2. Free samples are available by freight collect.
3. High quality goods, Perfect Pre-sales, and good designing service.
4. Welcome to visit our factory at anytime on site or online .
5. We will update you the production process after placing order by photos or online.
6. We have special after-sales team to solve your problem during using our products.
3. High quality goods, Perfect Pre-sales, and good designing service.
4. Welcome to visit our factory at anytime on site or online .
5. We will update you the production process after placing order by photos or online.
6. We have special after-sales team to solve your problem during using our products.
Company Profile
Luyang Energy-saving Materials Co., Ltd. was established in 1984 and listed in Shenzhen Stock Exchange in 2006(Stock Code:002088). Going through more than 30 years development, Luyang has become a world famous enterprise for new energy-saving materials researching, manufacturing and selling in the field of ceramic fibers,bio-soluble fibers, alumina fibers, rock wool fibers, microporous board and insulating firebricks. Products are in great demand nationwide and sold in more than sixty countries and regions,such as USA, Japan, Vietnam,EU. Products applied widely in the field of petrochemical refractory insulation, long-distance pipe network insulation, building fire insulation, shipping fire prevention, household appliances fire insulation, high-temperature insulation etc.
Our factory
Luyang has five production bases in Shandong,Inner Mongolia,Xinjiang,Guiyang and Suzhou. Luyang has an annual output of 300,000 tons of various ceramic fiber products and 200,000 tons of rock wool products.
