Products Description


Product Description
DS6600B-M9 is a high-performance 2D bluetooth and wireless 2.4G barcode scanner with leading CMOS image recognition technology.
It can easily read the paper, goods, screen and other media barcodes.
Widely used in manufacturing, warehouse, logistics, health care, retail chain, mobile payment, express delivery, inventory
management, food traceability, asset inventory,etc.



Features


Features
☆ Ergonomic design, comfortable using.
☆ Read all mainstream 1D 2D barcodes in the market easily. (3mil)
☆ Interface: USB, bluetooth 4.2, Wireless 2.4G.
☆ Ultra-low power consumption, continuous working time 24h.
☆ Bluetooth , long wireless distance 50m, can be used in mobile phone and PC.
☆ Widely used in supermarket, warehouse, mobile payment, chain stores.


Details Images


Product appearance picture display:




Product Parameters


Performance


Scan Type
CMOS
Light Source
lighting: white LED Aiming; Green LED，wavelength coverage 525nm
CPU
32-bit
Resolution
640*480
Reading precision
1D：≥5mil，2D：≥8.7mil @PCS90%
Decoding speed
25CM/S
Depth of field
5mil：50~130mm，13mil：50~270mm
Scan Mode
Manual , Auto Sense
Scan angle
Test Conditions： CODE39,10mil/0.25mm,PCS90%
Pitch:
±60°
Roll:
±360°
Skew:
±70°
Print Contrast Signal
≥25%
Ambient Light
Dark environment, indoor natural light
Wireless communication mode
Synchronization , storage
Wireless transmission distance
2.4GHz,200meters; Bluetooth 30meters（Open distance）
Storage
16Mb（over 100,000 Product code）
Battery capacity
2200mAh
Battery charging time
About 6.5 hours
Continuous working time
≥16hours
Symbologies
 1D： Codabar、Code39、Code32、Interleaved 2 of 5（ITF25）、Industrial 2 of 5、Matrix 2 of 5、Code93、Code11、Code128、Gs1-128、UPC-A、UPC-E、
EAN/JAN-8、EAN/JAN-13、ISBN、ISSN、GS1 databar、GS1 databar limited、GS1 databar expanded、ISBT
2D：PDF417、Micro PDF417、QR Code、Micro QR、Data Matrix、Aztec


Physical Parameter


Weight
≈160g（without cable）
Dimension
L180mm * W60mm * H80mm
Communication
USB、 Wireless 2.4G、 Wireless Bluetooth 4.2
Interface Type
USB
Power Supply
DC 5V@120mA(work）


Environmental


Operating
-20℃ to 55℃
Storage
-20℃ to 60℃
Humidity
5% to 95%（non-condensing）
Drop Height
1.5m
Temp. Test
30 minutes for high Temp., 30 minutes for low Temp.,
High Temp.
60℃
Low Temp.
-20℃
Transport
10H@125RPM


Accessories List


Cable
USB, connect the scanner to a host device and charging.
Receiver
Used to receive and transmit scanner data.


Company Profile


The factory shows as follows:






Company Certificate




Exhibition




Application




Contact




FAQ


FAQ
Q1: How do you make sure the high quality barcode scanner?
DYscan: we are pofessional manufacturer and developer of barcode scanner, with rich field experience for 18 years.
Professional QC team and testing machine (Engine age test,wire bend machine,switch life test,shock resistance test).
All our barcode scanners pass CE,FCC,ROSH certifications etc.

Q2: How do you make quality control?
DYscan: we have wire bend test 1 million times, buttons are tested 1 million times, all the devices will be tested before send out.

Q3: How long is the warranty time of barcode scanner?
DYscan: 12 months

Q4: How to control the performance stable?
DYscan: We take the flow line production in the whole processing. Every product will be tested 4 times at least before delivery.

Q5: Can you provide OEM or ODM service for barcode scanner?
DYscan: We can do OEM, such as printing your own logo, color box, user manual. And we have our own technical team to support ODM service.
