2. Productivity: 400000 skewer stick/8hours, need 4-5worker, use 380v voltage,
productivity can be increase to 800000skewer/8hour if increase 1 set SKEWER SHARPEN MACHINE
3. Usually 100kg wet bamboo can get BBQ stick ( diameter 2.5-3mm,length 15-30cm) 20000-4000 pieces 4. If you make incense sticks, you don’t need the sharpener
NO.
Name
Power
Function
1
Bamboo sawing machine
1.5 kw
sawing original bamboo
2
Bamboo-dissection machine
3 kw
cutting the round bamboo section into certain width pcs. 14 time /min
3
width-fixing knot remove machine slicing machine
3.7 kw
enhancing the shape of bamboo slice and setting the width and thickness of pieces by special process like cutting, paring, and shaving
4
Bamboo stick forming machine
9.1 kw
making bamboo filaments
5
Bamboo stick length-fix machine
0.75 kw
setting the length of the bamboo filament
6
Polishing machine
1.5 kw
polishing the bamboo or wood products
7
Stick sharpening machine
1.65 kw
Output: 50000 pieces/hour
8
Blade sharpening machine
0.55 kw
sharpen knives
Bamboo incense making machine
If you make bamboo incense sticks, you don’t need the sharpener for BBQ stick making line
Bamboo Toothpick Making machine
1. process :bamboo - cutting - bamboo stick -slicer -drawing mill -bleach -drying - cut to the fixed length -
polishing -sorting -sharping -packing.
2. two-heads pointed bamboo toothpicks & one head pointed toothpick . The normal size of the
toothpicks is diameter 2.0mm the length 65mm
3. For the two- head sharpened toothpick is about 800,000 /8 hour ,about 100 kg and needs 4-6 worker ,the
power should be 380v, if added another no.9 machine , the output would double,that is 1,600,000.
4. For the one head sharpened toothpick is about 600,000/8 hours.if added another no.9 machine ,
the output would double,that is 1,200,000.
5. Usually 100kg fresh bamboo can produce about 100,000-130,000 pieces with the size about
2.0 diameter length 65mm and drying to about 13-16kg.
NO.
Name
Power
Function
1
Bamboo Sawing Machine
1.5 kw
sawing original bamboo
2
Bamboo Dissection Machine
3 kw
cutting the round bamboo section into certain width pcs. 14 time /min
3
Wide Section Slicing Machine
3.7 kw
enhancing shape of bamboo slice and setting width and thickness of pieces by special process like cutting, paring, and shaving
4
Bamboo Stick Forming Machine
9.1 kw
making bamboo filaments
5
Stick Length Forming Machine
0.75 kw
setting the length of the bamboo filament
6
Toothpick Length Fixing Machine
2.75 kw
making the toothpick into the same length.
7
Toothpick Polishing Machine
1.5 kw
polishing the bamboo or wood toothpick
8
Toothpick Sorting Machine
0.55 kw
Organize messy toothpicks
9
Toothpick Sharpening Machine
1.65 kw
Output: 120000 pieces/hour
10
Multifunctional Tool Sharpener
0.55 kw
sharpen knives
Paper Bag Toothpick Packing Machine
Packing Way: :paper bag
Packing 1 or 2 toothpick into one paper bag
Function: two side or single side printing
Power:0.37kw
Pack speed:300-600bags/min
Dimension:1500*600*1300mm
Bottle Toothpick Packing Machine
Packing way: :bottle
Packing tens or hundreds toothpick into one bottle
Technical Data:
1.Power Supply: 220v+10% for 50hz
2.Power: 50w
3.Packing Speed: 10-30 times/min
Packing & Delivery
wood case and container suit for the Toothpick BBQ stick making machine
