Product Description
Open Type Ultrasonic Sensor Module
The ultrasonic sensor HC-SR04 uses sonar to determine distance to an object. It offers excellent non-contact range detection with
high accuracy and stable readings in an easy-to-use package. From 2cm to 400 cm or 1" to 13 feet. It operation is not affected by
sunlight or black material like Sharp rangefinders are (although acoustically soft materials like cloth can be difficult to
detect). It comes complete with ultrasonic transmitter and receiver module.
high accuracy and stable readings in an easy-to-use package. From 2cm to 400 cm or 1" to 13 feet. It operation is not affected by
sunlight or black material like Sharp rangefinders are (although acoustically soft materials like cloth can be difficult to
detect). It comes complete with ultrasonic transmitter and receiver module.
Module Working Principle
1.Adopt IO trigger through supplying at least 10us sequence of high level signal.
2.The module automatically send eight 40khz square wave and automatically detect whether receive the returning pulse signal.
3.If there is signals returning, through outputting high level and the time of high level continuing is the time of that from the
ultrasonic transmitting to receiving.
4.Test distance = (high level time * sound velocity (340M/S) / 2.
Buzzer Advantage
1.Automated machine dispensing,perfect product appearance .
2.Sound test, using decibels,frequency waveforms, impedance recognition, excellent product sound and good consistency.
2.Sound test, using decibels,frequency waveforms, impedance recognition, excellent product sound and good consistency.
Buzzer Application
Buzzer is generally used in intelligent wearable equipment, anti-theft system, medical equipment, industrial production, etc.
Main Series
Our main products are: Buzzer(piezo buzzer/magnetic buzzer/mechanical buzzer/SMD buzzer)；Ultrasonic Sensor(open ultrasonic sensor/waterproof ultrasonic sensor/hcar parking sensor/high frequency sensor)；Alarm Siren(piezo siren/ electronic siren/ backup alarm);Speaker(mylar speaker/mini speaker/mobilephone speaker).
Who Choose Us?
Packing and Delivery
FAQ
1.What's your MOQ?
MOQ depends on different series of products, pls contact with us.
2.Do you support OEM and ODM services?
Yes, we can customize products according to the drawing.
3.How about freight fee?
We cooperate with different express companies, enjoy the lowest discount.
4.Do you support after sales service?
The professional after-sales service team will solve all problems for you.
