Product Description
Automatic CZ purlin machine roll forming machine,one machine can make c purlin and z purlin both.automatic changing sizes,PLC control,easzy operation
material thickness | 1.5-3.0mm |
suitable material: | galvanized strips |
sizes of product: | c purlin:80-300mm z purlin:120-300mm |
voltage of machine: | 380/220/410/440,it can be customized |
color of machine: | blue or as your request |
driving of machine: | by oil motor |
Sizes of profile
C purlin width:80-300
Z purlin width:140-300mm
flange height:40-80mm (c purlin)
50-80mm(z purlin)
lips:10-2500(c purlin)
15-25mm(z purlin)
Supplu Component of Comlete Line
Description | Quantity (set) |
6Tmanual decoiler | 1 |
Guiding device | 1 |
Hydraulic pre cutter | 1 |
Forming system | 1 |
Transmission system | 1 |
Hydraulic guillotine&punching | 1 |
Support table | 2 |
Hydraulic station | 1 |
Control box | 1 |
Spare parts and tools | 1 |
General Parameters of machine
No | Item | Parameter |
1 | Forming Speed | Max25m/min(depend on quantity of punching) 10-15METERS/MIN depends on the quantity of punching holes |
2 | Forming station | Around 18 groups |
3 | Total Power | About 22 KW |
\\4 | Total Weight | About 9500KGS |
5 | Voltage | 380v,50hz,3p |
6 | Diameter of shaft | 60mm &80mm |
5 | Installation Size | 21 * 1.0 M*1.5 |
Main parts Material
No | Item | Parameter |
1 | Forming Shaft | 40CR with grinding process and heat treatment HRC28-32,twice CNC |
2 | Forming Roller | CR12 with vacuum heat treatment with hard chrome coatingHRC50-52 |
3 | Cutting Blade | Cr12MoV with hard treatment |
4 | Control System | PANASONIC PLC, others are Schneider etc. |
5 | Electrical motor | China quality brand |
6 | Touch screen | Win view |
7 | PLC | Panasonic |
8 | Rely | Schneider |
9 | Encoder | Omron |
Related Products
Packing&Shipping
all machines will be covered with plastic films,with steel wiring fixed in container.
After Sales Service
Company Introduction
specialized manufacturer of roll forming machine and exported to different countries.
FAQ
1) Q: Are you manufacturer or trading company?
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome your visit us and test machine by yourself in our factory.
6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.
7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are Gold supplier of Made-in-China with SGS assessment (Audit report can be provided).
A: We are manufacturer and trading company .
2) Q: Do you provide installing and training overseas?
A: Overseas machine install and worker training services are optional.
3) Q: How is your after sales support?
A: We provide technical support on line as well as overseas services by skillful technicians.
4) Q: How does your factory do regarding quality control?
A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.
5) How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) We welcome your visit us and test machine by yourself in our factory.
6) Q: Do you sell only standard machines?
A: No. Most machines are made to order.
7) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. We are Gold supplier of Made-in-China with SGS assessment (Audit report can be provided).
