Product Description
One machine for dual purposes, can be used for a variety of flexible warm-edge hollows and trough aluminum hollows. At the same time, it can automatically complete multiple functions without manual operations such as:automatic loading glass, automatic loading edge strips, automatic heating of rubber strips or butyl glue, multi-glass and large and small was combined , online inflation, automatic sealing, etc.
Parameter name | Description | ||
Length | 25M | ||
Width | 2.5M | ||
Height | 2.9M | ||
Producing warm edge strip | MAX glass size | 2000*2500mm | |
MIN glass size | 400*450mm | ||
Producing glass size | MAX glass size | 2000*2500mm | |
Glass thickness | 3-8mm | ||
Processing speed(1000*1000)mm | Double glass 52 seconds per piece Triple glass 76 seconds per piece | ||
Thickness of washed | 3-8mm | ||
Product features
Full-process PLC control system, servo motor drive, touch screen interface operation
Automatically identify the film layer of coated glass or Low-E glass (optional)
Washing low-E glass online or offline
Air blade of glass washing machine was adjusted by thickness of glass
Digital control production line intermittent work energy saving system
The speed of cleaning Low-E glass brush can be driven by frequency conversion
Aluminum frame automatic positioning system
Glass automatic positioning system
Automatically identify the film layer of coated glass or Low-E glass (optional)
Washing low-E glass online or offline
Air blade of glass washing machine was adjusted by thickness of glass
Digital control production line intermittent work energy saving system
The speed of cleaning Low-E glass brush can be driven by frequency conversion
Aluminum frame automatic positioning system
Glass automatic positioning system
Our transportation
Why choose us?
Our Services & Strength
1.Carton minumum order
2.Delivery on time
3.Free samples
4.24*7Hours online service
5.Flexiable&Secured payment
6.0 Worry about quality
7.Our team are young but professional
2.Delivery on time
3.Free samples
4.24*7Hours online service
5.Flexiable&Secured payment
6.0 Worry about quality
7.Our team are young but professional
Company Introduction
Liaoning Alger Building Materials And Machine Co.,LTD locates in Bayuquan, Yingkou,Liaoning province, a beautiful coastal city. Alger was established in 2008. Alger is committed to produce and provide environmental energy-saving building materials and advanced intelligent efficiency machineries with better technical support and service. We own several subsidiaries to manufacture materials.
Our main products scope :
I.Insulating Glass Sealing Materials
II.Adhesive Composition
III.Glass Deep Processing Equipments
IV.Fittings
VI.Hardware for Door and Window
Our team is young in average age but with mordern spirit of high technology. The products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success.
