Products Description






Brief Introduction
Supersonic frequency harden and precision ground bedway available on repuestEuro-standard electrical control board available on request


Characteristic





Its relatively simpler structure also remain in full rigid and high strength hardened steel
base construction.






Full scale of accessories are provided for each Almaco Bench Lathe who still be able to carry on turning, drilling, boring,
knurling and threads processes


Standard Accessories
4 Jaw chuck 8" (dia. 200mm)
Face plate 12" (dia. 300mm)
Steady rest
Follow rest
Coolant system
Work light
Cabinet






Main Specifications:


Model Item
BL0632B
Max. swing diameter over bed
13" (330mm)
Max. swing diameter over gap
183 /4"(476mm)
Swing diameter over carriage
71 /4" (185mm)
Bed width
73 /8" (186mm)
Max. length of workpiece (Two centers)
30"(750mm)/40"(1000mm)
Spindle nose
D1-4
Spindle bore
11/2"(F38mm)
Taper of hole in spindle morse
No.5
Spindle speed steps
8
Spindle speed range
70-2000r/min
Inch thread
40-21 /4 T.P.I/20
Metric thread
0.45-10mm/28
Longitudinal feed range
0.0013-0.0173in/r (0.26-0.348mm/r)
Max. travel of tailstock quill
35 /8"(95mm)
Taper hole of tailstock
No.3
Electric motor
2HP(1.5KW)11v or 220V (1ph)
Net weight/Gross weight (1000mm )
495/595kg
