Датчик уровня жидкости 4-20 мА 0-5

Описание и отзывы

Характеристики



Application	Liquid Level
Range	can be customized within the range of 0 ~ 0.2 ~ 500m
Accuracy	0.5FS% (recognized) 0.3FS% (need to be customized)
Limit overload	200%
Medium temperature	Medium temperature
Power supply voltage	DC24V [15 ~ 36VDQ (default), 12VDC power supply needs to be customized
Input signal	4 ~ 20mA, 0 ~ 5V, 1 ~ 5V , 0 ~ 10V,RS485, RS232, wireless short distance (within 2000 meters)  network transmission, GPRS wireless transmission.
Stability	± 0.2% FS/year
Sealing level	IP68
Process connection	Input type, put into the test liquid
Electrical interface	Connect the tight-wire waterproof nose to the five-core air guide cable



Product Feature

[1] Imported diffusion silicon pressure sensing chip

[2] Advanced placement technology, with zero and span compensation, temperature compensation

[3] High-precision, high-stability amplifier IC

[4] Up to twice the instantaneous pressure shock

[5] 3 types of intelligent protection (overvoltage / overcurrent / reverse connection)

[6] Various input value numbers, including current type and voltage type

[7] Full-scale compensation, temperature compensation

[8] Protection grade up to IP68 standard, can be immersed in water for a long time
