USFULL VFD частотный инвертор 5 кВт трехфазный от 220 В

Описание и отзывы

Характеристики

USFULL VFD Frequency Controller 4KW Three Phase 220V Frequency Inverter 50Hz to 60Hz with RS485

Model No.	Input Voltage	Rated Power (KW)	Rated Input Current(A)	Rated Output Current(A)	Compitable Motor(KW)
FU9000A-1R5G-S2	single phase 220V±15%	0.5	14.2	7	1.5
FU9000A- 2R2G-S2		1.2	23	10	2.2
FU9000A-0R7G -S	three phase 220V±15%	0.75	5	4.5	0.75
FU9000A-1R5G-2		1.5	7.7	7	1.5
FU9000A- 2R2G-2		22	11	10	2.2
FU9000A-004G- 2		3.7	17	16	3.7
FU9000A-5R5G-2		5.5	21	20	5.5
FU9000A-7R5G-2		7.5	31	30	7.5
FU9000A-011G-2		11	43	42	11
FU9000A-015G-2		15	56	55	15
FU9000A-018G-2		18.5	71	70	18.5
FU9000A-022G-2		22	81	80	22
FU9000A-030G-2		30	112	110	30
FU9000A-037G-2		37	132	130	37
FU9000A-D45G-2		45	163	160	45
FU9000A-055G-2		55	181	190	55
FU9000A-0R7G-4	three phase 380V±15%	0.75	3.4	25	0.75
FU9000A-1R5G-4		1.5	5	3.7	1.5
FU9000A-2R2G-4		22	5.8	5	22
FU9000A-004G/5R5P-4		4/5.5	10/15	9/13	4/5.5
FU9000A-5R5G/7R5P-4		5.5/7.5	15/20	13/17	5.5/7.5
FU9000A-7R5G/011P-4		7.5/11	20/26	17/25	7.5/11
FU9000A-011G/015P-4		11/15	26/35	25/32 .	11/15
FU9000A-015G/018P-4		15/18.5	35/38	32/37	15/18.5
FU9000A-018G/022P-4		18.5/22	38/46	37/45	18.5/22
FU9000A-022G/030P-4		22/30	46/62	45/60	22/30
FU9000A-030G/037P-4		30/37	62/76	60/75	30/37
FU9000A-037G/045P-4		37/45	76/90	75/90	37/45
FU9000A-045G/055P-4		45/55	90/105	90/110	45/55
FU9000A-055G/075P-4		55/75	105/140	110/150	55/75
FU9000A-075G/090P-4		75/90	140/160	150176	75/90
FU9000A-090G/110P-4		90/110	160/210	176/210	90/110
FU9000A-110G/132P-4		110/132	210/240	210/250	110/132
FU9000A-132G/160P-4		132/160	240/290	250/300	132/160
FU9000A-160G/185P-4		160/185	290/330	300/340	160/185
FU9000A-185G/200P- 4		185/200	330/370	340/380	185/200
FU9000A-200G/220P-4		200/220	370/410	380/415	200/220
FU9000A-220G/250P-4		220/250	410/460	415/470	220/250
FU9000A-250G/280P-4		250/280	460/500	470/520	250/280
FU9000A-280G/315P-4		280/315	500/580	520/600	280/315
FU9000A-315G/350P-4		315/350	580/620	600/640	315/350
FU9000A-350G-4		350	620	640	350
FU9000A-400G-4		400	670	690	400
FU9000A-500G-4		500	835	860	500

FAQ:

Q 1: What's the function of USFULL VFD?

   A: USFULL VFD control the speed and frequency of motors, which is widely used in industrial control, automation system and pump system.



Q 2: How to choose suitable VFD for my machine?

   A: Please send us your machine details, we will provide you most suitable model type.



Q 3: What's the payment term?

   A: We accept T/T, L/C, D/A, D/P, WESTERN UNION, PAYPAL, CASH, etc.



Q 4: What's the delivery time?

   A: For 2000pcs inverter, it usually takes one week to finish.



Q 5: What's the standard of package?

   A: Below 75kW, it's carton package; 75kW and above, it's wooden package.



Q 6: How you control quality?

   A: Our inverters strictly follow ISO9001 quality control system. After four times quality inspect and high temperature testing we will print "QA" pass.



Q 7: What's your production capacity?

   A: We can finish 8000pcs inverter per month. Also we can receive rush order, more details please contact us.



Q 8: Which market do you already sell?

   A: We already ship to Europe, Middle East, South America, Asia, Afria, etc.



Q 9: What kind of certificate you have?

   A: We have ISO, CE, CB, TUV, etc.



Q 10: Do you accept OEM business?

   A: Yes, we accept OEM and ODM with your autherization. For some items we have MOQ. For more questions, feel free to send us inquiry.
