Physical performance | ||||||||
Item | Class A | Class C | Class C | |||||
Apparent density (g/cm3) | Not smaller than regular standard | |||||||
Thermal conductivity W/ (m.K) | ≤ 0.45 | ≤ 0.35 | ≤ 0.25 | |||||
Water absorption (%) | ≤ 28 | ≤ 40 | — | |||||
Moisture Movement (%) | DS≤0.25 PS≤0.50 | |||||||
Noninflammability | GB 8624 Class A | |||||||
After 24 hours of testing, wet marks were allowed to appear on the reverse side of the board, but no water droplets appeared. | — | |||||||
Freezing test | Freezing resistance | No cracks and hierarchy after 100times (Class A) and 25 times (Class B) freeze-thaw cycles. | — | |||||
Ratio of bending strength | ≥ 70% | — | ||||||
Heat-rain testing | No cracks and hierarchy after 50times (Class A) and 25 times (Class B) freeze-thaw cycles. | — | ||||||
Hot water performance | Ratio of bending strength ≥60% | — | ||||||
No cracks and hierarchy after 50times (Class A) and 25 times (Class B) freeze-thaw cycles, Ratio of bending strength ≥70%. | — |
Thickness | Length | Width |
5mm | 2440-3000mm | 1220mm |
6mm | ||
8mm | ||
10mm | ||
12mm | ||
15mm | ||
18mm | ||
20mm |
