Product Description
Vertical Freeze DryerBK-FD12S(-56/80)
Introduction:
The tabletop type and vertical type freeze dryer is suitable for freeze drying test of laboratory biomedical samples.
Widely used drugs, biological products, chemical and food industries. On the heat-sensitive substances such as antibiotics, vaccines, blood products, hormones and other biological tissue enzymes, freeze-drying technology is applied.
The tabletop type and vertical type freeze dryer is suitable for freeze drying test of laboratory biomedical samples.
Widely used drugs, biological products, chemical and food industries. On the heat-sensitive substances such as antibiotics, vaccines, blood products, hormones and other biological tissue enzymes, freeze-drying technology is applied.
Advantages:
1. The 7 inch LCD display panel.
2. With historical data inquiry function.
3. The machine is equipped with USB interface on control panel.
4. Large capacity Ice condenser trap and without coil inside.
5. Cascade refrigeration technology.
6. The pre-freeze shelf can be used as guide barrel to speed up the drying rate.
7. Ice condenser trap and operation panel are made by stainless steel.
8. Drying cabinet is transparent which is visual and safe.
9. The shelves are stainless steel, which can be adjustable per the requirements.
1. The 7 inch LCD display panel.
2. With historical data inquiry function.
3. The machine is equipped with USB interface on control panel.
4. Large capacity Ice condenser trap and without coil inside.
5. Cascade refrigeration technology.
6. The pre-freeze shelf can be used as guide barrel to speed up the drying rate.
7. Ice condenser trap and operation panel are made by stainless steel.
8. Drying cabinet is transparent which is visual and safe.
9. The shelves are stainless steel, which can be adjustable per the requirements.
Specification
Model | BK-FD12S(-56/-80) | BK-FD12P(-56/-80) | BK-FD12T(-56/-80) | BK-FD12PT(-56/-80) | |||||||
Type | Standard chamber | Standard chamber with 8 port manifold | Stoppering chamber | Stoppering chamber with 8 port manifold | |||||||
Freeze Drying Area | 0.12 m2 | 0.09 m2 | |||||||||
Tray | 4 pcs | 3 pcs | |||||||||
Height Between Trays | 50mm | 68mm | |||||||||
Cold Trap Temperature | ≤-56℃/-80℃ | ||||||||||
Cold Trap Capacity | 9.5L | ||||||||||
Cold Trap Size (Dr*H) | Φ215*260mm | ||||||||||
Vacuum Degree | <10 Pa | ||||||||||
Water Capture Capacity | 4kg/24h | ||||||||||
Tray Size (D*H) | Φ200*20mm | ||||||||||
Freeze Drying Time | 24h | ||||||||||
Loading Capacity/Shelf (Liquid) | 0.3L | ||||||||||
Total Loading Capacity (Liquid) | 1.2L | 0.9L | |||||||||
Drying Chamber Size (D*H) | Φ260*310mm | Φ260*450mm | Φ260*450mm | ||||||||
Can Load Vials Qty | Φ22mm | 260 | 195 | ||||||||
Φ16mm | 480 | 360 | |||||||||
Φ12mm | 920 | 690 | |||||||||
Refrigerant | R600a+R290+R23 | ||||||||||
Cooling System | Air cooling | ||||||||||
Consumption | -56℃: 0.9kW,-80℃: 1.5kW | ||||||||||
Power Supply | AC220V,50Hz,60Hz (single phase); 110V/220V,60Hz (single phase, only for -56℃) | ||||||||||
Standard Accessory | Vacuum pump 2L/S, 8m3/h (for all models),Conical-mouth flasks 500mlx8 (only for model BK-FD12P/PT) | ||||||||||
Optional Function & Accessory | Tray heating (for all models), Cold trap defrosting (for all models), Conical-mouth flask and wide-mouth flask (for BK-FD12P/PT), Import vacuum pump | ||||||||||
External Size (W*D*H) | 460*620*920/1370mm | ||||||||||
Package Size (W*D*H)mm/ Gross Weight | Main Body | 1000*700*570/90kg | 1000*700*570/90kg | ||||||||
Drying Chamber | 300*300*350/12kg | 350*350*570/12kg | |||||||||
Vacuum Pump | 590*380*220/22kg | 590*380*220/22kg | |||||||||
