Грузовик для горных работ SRT45

Описание и отзывы

Характеристики



---

SRT45 45t Off-highway Truck Mining Truck





Feature

1.Full views
Panoramic windshiel with a wider view;

The blind area of the short locomotive structure is 2 metres shorter than the similar products.Impeccable rearview mirror layout make the operation safer.
2.Steering mechanism and suspension system
The reinforced articulated bearing ensures the reliability of the vehicle during steering and bumping.
3.Hydraulic system
Advanced hydraulic matching technology, the oil temperature is 5℃ lower than similar products. Independent functional modules will not interfere with each other.
4.Steering mechanism
Large steering Angle design which be better than the industry level.

Strong mobility, operation efficiency significantly improved.
5.Suspension system
Suspension cylinder with patented technology, the root mean square value of vibration acceleration is 20% lower than similar domestic products.

McPherson independent suspension can effectively avoid the eccentric wear caused by the lateral force of the traditional suspension cylinder in the industry, improve the life of the suspension cylinder and reduce the tire wear.



Specification

Model	SRT45	SRT55D	SKT90E	SRT95C
Automatic/Manual	Automatic	Automatic	Automatic	Automatic
Capacity (Struck/Heaped)	22/29.5m³	26/35m³	31/35m³	42/60m³
Displacement	16.1L	16.1L	0L	30.5L
Engine Model	AD1650VE-B	TAD1643VE-B	YUEBOO	QST30-C1050
Gearbox Type	FAST FC6A250DPR	AVITEC H6620AR	YUEBOO	H8610AR
Left/Right Hand Drive	Left	Left	Left/Right	Left
Load Weight	45T	55T	60T	95T
Lubrication System	Manual/Automatic	Manual/Automatic	Manual/Automatic	Manual/Automatic
Maximum Gradeability	30%	30%	36%	30%
Maximum Torque	2400NM	3260NM	5100NM	4629NM
Minimum Turning Radius	9530mm	9540mm	11000mm	12000mm
Net Weight	34.5T	40T	32T	65T
Number/Type Of Cylinders	6/Straight type	6/Straight type	-	12/V type
Size	8610x4180x4450mm	9125x4150x4505mm	8967x3468x4308mm	10100x5420x4890mm
Total Power	405kW	565kW	580kW	728kW
Tyre	21.00R35 Radial Tire	24.00R35 Radial Tire	14.00R25 Wire Tyre	27.00R49 Radial Tire
