full-electric stacker lift stacker china electric pallet forklift stacker 1000kg battery powered pedestrian economic electric
Product Description
The DGXZ-12 is a perfect standing-on pallet stacker,
With a rated capacity of 1200 kg/2645lbs
Lifting height 2m-3.5m
The compact and durable design is suitable for diverse duties in different workplaces.
Standard configuration
- Solid PU tire
- Electromagnetic brake
- 24 voltage 60 Ampere Hour Battery
- Working for 6-8 hours
- Rated capacity 1.5 ton
- Electric quantity display
- Over-discharge protection
- Lifting height 200 mm
- Emergency power-off switch
Optional configuration
- Fork dimension±300mm
- Lithium battery
- Remote control
- Large battery capacity
| Model | DGXZ12-20 | DGXZ12-25 | DGXZ12-30 | DGXZ12-35 | |
| Power Type | Battery | Battery | Battery | Battery | |
| Operation Type | Standing Driving | Standing Driving | Standing Driving | Standing Driving | |
| Load Capacity | kg | 1200 | 1200 | 1200 | 1200 |
| Load Center | mm | 500 | 500 | 500 | 500 |
| Lift Height | mm | 2000 | 2500 | 3000 | 3500 |
| Wheelbase | mm | 1300 | 1300 | 1300 | 1300 |
| Overall Dimension(L×W) | mm | 1750×800 | 1790×800 | 1830×800 | 1870×800 |
| Mast raise/unraise Height | mm | 1580/2550 | 1830/3250 | 2080×3750 | 2230×3750 |
| Fork Dimension | mm | 1150×140×60 | 1150×140×60 | 1150×140×60 | 1150×140×60 |
| Fork Width Min./Max. | mm | 550/685 | 550/685 | 550/685 | 550/685 |
| Min. Ground Clearance | mm | 90 | 90 | 90 | 90 |
| Turning Radius | mm | 1688 | 1699 | 1768 | 1768 |
| Min.Right Angle Channel Width | mm | 1000 | 1000 | 1000 | 1000 |
| Self Wight(with battery) | kg | 550 | 583 | 616 | 649 |
| Battery Weight | kg | 52 | 52 | 52 | 52 |
| Wheel Type (driving/turning) | Solid PU | Solid PU | Solid PU | Solid PU | |
| Driving Wheel Sizes | mm | 210×75 | 210×75 | 210×75 | 210×75 |
| Auxiliary wheel Sizes | mm | 115×55 | 115×55 | 115×55 | 115×55 |
| Loading Wheel Sizes | mm | 80×70 | 80×70 | 80×70 | 80×70 |
| Tread,Front | mm | 520 | 520 | 520 | 520 |
| Driving Motor | kw(60min) | 0.8 | 0.8 | 0.8 | 0.8 |
| Lifting Motor | kw(60min) | 2.2 | 2.2 | 2.2 | 2.2 |
| Battery Dimension | mm | 271×174×213 | 271×174×213 | 271×174×213 | 271×174×213 |
| Battery Voltage/Capacity | V/ah | 24/135 | 24/135 | 24/135 | 24/135 |
| Controller | DC | DC | DC | DC | |
| Working Pressure | mpa | 12 | 12 | 12 | 12 |
| Driving Speed | km/h | 4/4.5 | 4/4.5 | 4/4.5 | 4/4.5 |
| Lifting Speed | mm/s | 45/55 | 45/55 | 45/55 | 45/55 |
| Lowering Speed | mm/s | 40/55 | 40/55 | 40/55 | 40/55 |
| Max Climbing Ability | % | 3 | 3 | 3 | 3 |
| Service Braking | electromagnetic induction | electromagnetic induction | electromagnetic induction | electromagnetic induction | |
| Parking Braking | electromagnetic induction | electromagnetic induction | electromagnetic induction | electromagnetic induction | |
| Driving Type | Electric | Electric | Electric | Electric | |
| Steering Type | Manual | Manual | Manual | Manual | |
| Noise Level | 68 | 68 | 68 | 68 | |
| Waterproof Grade | IP54 | IP54 | IP54 | IP54 |
FAQ
FAQ
1.We have no agent or dealers ,so the price that we provided is factory price.
About quality guarantee:The price that we provided is the lowest price,we have no profit to support over sea service.
If there is some question with your machine ,we will adopt DHL, express new parts to you in 3 days,and our technologist will guide you or your technologist how to repair it.We provide parts for free in 12 months , not include the freight fee.
2:Question: ××× company's price is cheaper than you,I want the cheap one.
Quality comes more important than price. They will not sale the machine with no profit . Excessive low price means inferior parts and unconcernedly assemble. Our parts all purchased by our professional buyer,they have plenty experience to choose good parts in good price.The education background of our workers are junior college or higher than this ,plenty of assemble experience.We have professional quality inspector ,before our machine out of our factory,we test every machine strictly.
3:Question:Is there any risk to order your products.
Do not worry, we have plenty of experience,we have professional transport company and ship company that established long term cooperate relationship with us. We ask best freight fee for our customer.Any problem please feel free to contact us , we provide 7*24 hours service, we are glad to provide our service any time.
4:Question: How long should I wait till I receive my product?
If you purchase small machine and need it hurry,we can contact DHL for you . It can be send to you in 3 days. Large machine we use container or RORO for customer AS SOON AS POSSIBLE.
The Reasons Why Choose IDEAL
1. All the machines Up to 1 year quality warranty, in time after-service.
2. Widest range of light construction machinery. One-station purchasing.
3. Very Competitive price with top quality.
4. No minimum order limit, trial order is welcome.
5. Strong Engineering team for OEM and ODM service.
6. Highly trained staff provide professional and friendly service.
7. Easier communication by foreign sales.
WHAT WE CAN DO FOR YOU:
√Most competitive price by actively seeking the best options and manage the supply chain.
√A strong R&D Team and strict QC system ensure the quality
√Large stock and quick delivery than every competitor
√1-year warranty and best after-sale service support by our team.
HOW WE CAN GROW TOGETHER:
√Giving my best solution based on my professional experience
√Giving your best support on products perfect balance between performance and cost
√Help you develop and win more market share on your side
√We believe in delivering value through innovation, we believe in an open and honest relationship, we believe in speed-to-market. And DO NOT believe in shortcuts.
√If you have the same core value, we are glad to be your partner.
√Giving my best solution based on my professional experience
√Giving your best support on products perfect balance between performance and cost
√Help you develop and win more market share on your side
√We believe in delivering value through innovation, we believe in an open and honest relationship, we believe in speed-to-market. And DO NOT believe in shortcuts.
√If you have the same core value, we are glad to be your partner.
