DEMUDA High Quality 3500W MPPT All In One Pure Sine Wave Power Off Grid 24V 48V with Wifi 5.5KW Hybrid Solar
- Категории: Solar Inverter >>>
- Поставщик: Guangzhou,Demuda,Optoelectronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Built-in 100A MPPT Solar Charge Controller Pure Sine Wave Hybrid Inverter
* 3500W and 5500W Pure sine Wave Inverter 24V DC to 220V AC, built in 100A Mppt charge controller, is a new all-in-one hybrid solar charge inverter, Max 5000W 100A 220V/230v/240v Input , Fit for 24V 48V Lead-Acid(seal, AGM,Gel,Flooded) and Lithium battery.Support Utility/Generator/Solar Charge. For 110V could be ordered, pls contact with our sales.
* 24V 48V hybrid Inverter, applies Advanced MPPT technology Charging with an efficiency of 94% and inverter with DC to AC advancedSPWM technology which output pure sine wave power.
* LCD display design for display of system data and operating status, Intelligent variable speed fan to efficiently dissipate heat and extend system life.
* Complete protections, including short circuit protection, over voltage and under voltage protection, overload protection,
reverse protection, etc.
* 3500W and 5500W Pure sine Wave Inverter 24V DC to 220V AC, built in 100A Mppt charge controller, is a new all-in-one hybrid solar charge inverter, Max 5000W 100A 220V/230v/240v Input , Fit for 24V 48V Lead-Acid(seal, AGM,Gel,Flooded) and Lithium battery.Support Utility/Generator/Solar Charge. For 110V could be ordered, pls contact with our sales.
* 24V 48V hybrid Inverter, applies Advanced MPPT technology Charging with an efficiency of 94% and inverter with DC to AC advancedSPWM technology which output pure sine wave power.
* LCD display design for display of system data and operating status, Intelligent variable speed fan to efficiently dissipate heat and extend system life.
* Complete protections, including short circuit protection, over voltage and under voltage protection, overload protection,
reverse protection, etc.
* This inverter does not include WiFi module, please contact with our sales for additional purchase.
【LCD Setting】: LCD display offers easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
【Protection Function】: Overload/ Over temperature/ Short circuit protection. Smart battery charger design, Cold start function.
【MULTI-ROLE USE】: Single-phase 220V AC output hybrid inverter, 60Hz/50Hz can be setting；Output can powered by utility directly or battery or PV in battery mode. Support lead-acid batteries and lithium batteries.
【WIDLY APPLICATION】: This all in one solar inverter can power all kinds of appliances in home, farm or office, such as tube light, fan, refrigerator, air conditioner, ect. Notice: inverter is only suitable for 220V system and not suitable for 110V system!
【Protection Function】: Overload/ Over temperature/ Short circuit protection. Smart battery charger design, Cold start function.
【MULTI-ROLE USE】: Single-phase 220V AC output hybrid inverter, 60Hz/50Hz can be setting；Output can powered by utility directly or battery or PV in battery mode. Support lead-acid batteries and lithium batteries.
【WIDLY APPLICATION】: This all in one solar inverter can power all kinds of appliances in home, farm or office, such as tube light, fan, refrigerator, air conditioner, ect. Notice: inverter is only suitable for 220V system and not suitable for 110V system!
Technical Specifications
Model | 3.5K | 5.5K | ||
The rated power | 3500VA/3500W | 5500VA/5500W | ||
INPUT | ||||
Voltage | 230VAC | |||
Selectable Voltage Range | 170-280VAC (For Personal Computers) 90-280VAC (For Home Appliances) | |||
Frequnecy Range | 50Hz/60Hz (Auto sensing) | |||
OUTPUT | ||||
AC Voltage Regulation (Batt. Model) | 230VAC ± 5% | |||
Surge Power | 7000VA | 11000VA | ||
Power factor | 1.0 | 1.0 | ||
Efficiency(Peak) | 90%~93% | |||
Transfer Time | 10ms (For Personal Computers ) 20ms (For Home Appliances) | |||
Wave form | Pure Sine Wave | |||
BUILD-IN BATTERY | ||||
Battery Voltage | 24VDC | 48VDC | ||
Floating Charge Voltage | 27VDC | 54VDC | ||
Overcharge Protection | 33VDC | 63VDC | ||
MPPT SOLAR POWER INVERTER & AC CHARGER | ||||
Max. PV Array Open Circuit Voltage | 500VDC | 500VDC | ||
Max. PV Array Power | 120-450VDC | 120-450VDC | ||
MPPT Range @Operating Voltage | 4000W | 5000W | ||
Max. Solar Charge Current | 100A | 100A | ||
Max. AC Charge Current | 60A | 60A | ||
Max. Charge Current | 100A | 100A | ||
Max. Efficiency | 98% | |||
PHYSICAL | ||||
Products Dimension, L*W*H(mm) | 476*350*118 | |||
Packing size, L*W*H(mm) | 520*402*165 | |||
Net Weight (kgs) | 11.5Kg | 11.8Kg | ||
G.W. kg | 12.5Kg | 12.8Kg | ||
Communication Interface | USB/RS232/RS485/Bluetooth/Dry-Contact | |||
OPERATING ENVIRONMENT | ||||
Humidity | 0% to 95% Relative Humidity (Non-condensing) | |||
Operation Temperature | -10℃ to 50℃ | |||
Storage Temperature | -15℃ to 60℃ | |||
Established professional after-sales service team,24 hours online listen to your needs,for you to solve time product consulting and technical questions.
Company Profile
FAQ
1.Do you offer OEM/ODM service?
Yes, our factory and designer team have rich experience in offering OEM/ODM service.
2.Why we can choose you?
1)Reliable——we are the real company,we dedicate in win-win.
2)Professional——we offer the products exactly you want.
3)Factory---we have factory, so have reasonable price.
3. Can you accept sample order?
Yes,we can. Before large orders, we can provide samples for your testing.
4.What is your lead time?
1)Sample orders will be delivered from our factory within 3 working days.
2)General orders will be delivered from our factory within 15 working days.
3)Big orders will be delivered from our factory within 25 working days at most.
5. What is your payment terms?
We accept Alibaba Trade Assurance payment, T/T in advance.Then Western Union, PayPal or L/C.
6.Can you accept Trade Assurance Order?
Yes,we will be appreciated if you can place Trade Assurance order on our Alibaba
7.What is your shipment?
1)By EMS,DHL,FedEx,TNT,UPS or other express.
2)By our forwarding agent(by air or by sea).
3)By your own forwarding agent.
4)By domestic forwarding agents to any city in China.
Yes, our factory and designer team have rich experience in offering OEM/ODM service.
2.Why we can choose you?
1)Reliable——we are the real company,we dedicate in win-win.
2)Professional——we offer the products exactly you want.
3)Factory---we have factory, so have reasonable price.
3. Can you accept sample order?
Yes,we can. Before large orders, we can provide samples for your testing.
4.What is your lead time?
1)Sample orders will be delivered from our factory within 3 working days.
2)General orders will be delivered from our factory within 15 working days.
3)Big orders will be delivered from our factory within 25 working days at most.
5. What is your payment terms?
We accept Alibaba Trade Assurance payment, T/T in advance.Then Western Union, PayPal or L/C.
6.Can you accept Trade Assurance Order?
Yes,we will be appreciated if you can place Trade Assurance order on our Alibaba
7.What is your shipment?
1)By EMS,DHL,FedEx,TNT,UPS or other express.
2)By our forwarding agent(by air or by sea).
3)By your own forwarding agent.
4)By domestic forwarding agents to any city in China.
After Service
Regarding after-sales service, please be aware:
1. If the customer disassembles the product without our permission and reflects the product problem, no compensation will be paid.
2. If there is a problem with the product, please send the photos and videos during use to the corresponding business. The business will guide you on how to detect and provide you with solutions, please do not disassemble the product without authorization.
3. Please browse the details page parameters and pictures in detail before placing an order, so as not to cause unnecessary after-sales service.
1. If the customer disassembles the product without our permission and reflects the product problem, no compensation will be paid.
2. If there is a problem with the product, please send the photos and videos during use to the corresponding business. The business will guide you on how to detect and provide you with solutions, please do not disassemble the product without authorization.
3. Please browse the details page parameters and pictures in detail before placing an order, so as not to cause unnecessary after-sales service.
