Трехфазный автономный Солнечный Инвертор 150 кВт с немодулированным синусоидальным

Mode

GK60K

GK80K

GK100K

GK120K

GK140K

GK150K

GK200K

Rated power

60KW

80KW

100KW

120KW

140KW

150KW

200KW

 Battery Voltage

360V/384VDC

Phase

Three-phase+N+G

Nominal voltage

380VAC±1%(Steady state load),380VAC±3%(Load fluctuation)

Input Frequency rage

50Hz±0.1Hz

Current peak ratio

3:1 MAX

Output waveform

Pure sine wave

Total harmonic distortion

Linear load < 3%; nonlinear load < 5%

Transient load voltage transients (from 0 to 100%)

<±5%

Instant recovery time

<10ms

Balance load voltage

<±1%;<±5%(Unbalanced load voltage)

Overload capacity

100%~110%:30s;110%~130%:10s;>130%:1s

Inverter efficiency

>89%

communication interface

RS232,(485,snmp, Options)

Operating temperature

0~40℃

Relative humidity

(non condensing)

30%~90%

Operating altitude

(maximum)

<1000Meters(every increased 1000Meters decrease power1%,highest5000Meters)

cooling method

Forced air cooling

NoisedB(Depending on load and temperature)Distance to machine1M

≤58dB

Case color

Brack

Easy maintenance

The front / upper / left and right sides can be opened.

* the above data for reference, if there is a change in kind prevail.
