Токарный станок с ЧПУ VMC
US $9600-$10000
Автоматическое Измерение двухъядерный пульт дистанционного управления Cnc Roiter
- Категории: Machine Centre & Parts >>>
- Поставщик: Shanghai,Weihong,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Item | Specification |
Number of Axes Supported | 3-5 axes |
CPU | Dual cores |
CPU Clock Speed | 2.17GHz |
RAM | 2GB |
Storage | 60GB |
Monitor Dimension | 10.4 |
I/O | 800×600（SVGA） |
I/O | Standard: 28/8; Extended terminal board: 8/8(non-cascade connection),10/10 (cascade connection) |
Performance Indicator | The product stands EMI/Electrical fast transient immunity/Surge immunity tests and conforms to the fourth grade protection standards of GB/T 17626.5-2008. Resistance to vibration conforms to the GB/T 2423.10-2008 Standards. The product stands rigid temperature tests and conforms to the industrial standards of GB/T 2423.102-2008. |
Spindle | Analog Voltage Output 0-10V |
Tool Magazine | Linear tool magazine,Disk-type tool magazine |
Tool Measurement Mode | Auto measurement,Manual measurement |
Tool Measurement Type | Fixed calibration, Mobile calibration, First calibration & Calibration after tool change |
Circular Interpolation | Three axes linkage |
Compensation | Screw error compensation, Backlash compensation, AQE compensation, Tool compensation |
Supported File Format | *.g；*.nc；*.ug;*.demo;*.iso;*.eng;*.cut;*.dxf;*.plt;*.txt |
Internet(Ethernet) | LAN communication, Front USB interface, Two-way transmission between the system and PC |
WCS Setting | Supporting WCS G54-G59 and 120 extended WCSs |
Processing Technology | Array function, Mirror&rotate, Multi-layer machining, Cycle machining |
Software Language | Chinese, English |
Interpolation Algorithms | S-type,LEP and Acceleration T-type algorithms |
CNC Software Alarm | Alarms of program error, operation error, over-travel error, PLC error and IO communication error |
Successful Cases
Recommend Products
Company Introduction
Certifications
Packing & Transportation
FAQ
1. Are you factory or only company?
We are manufacturer providing professional motion control system solutions with strong R&D strength and high quality service team.
2.Why we can choose you?
Specialized: Provide perfect products by specializing in what we are adept in!
Concentrated: Satisfy customers by patiently listening to their opinions and demands!
Focused: Make innovations constantly by single-heartedly devoting to product R&D!
3.Can you do OEM product?
Yes, we are able to do OEM.
4.How long is your delivery time?
Generally it is 3-7 working days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
5.What is your terms of payment ?
100% in advance.
6.When I got this product, but I don’t know how to use it. What should I do?
We will provide user manual and video of the product. In addition, our engineer can also provide training online.
7.If some problems happen to this product during the warranty period, what should I do?
We will provide 1 Year Warranty, and will supply free parts during the product warranty period if the product has some problems.
We also supply free life long after-sales service. Thus, any problems, just feel free to let us know, we will provide you solutions.
8. What’s package, will it protect the products? How is the shipping method?
As per your actual address, we can effect shipment by sea, by air, by truck or railway. Also we can send the product to your worksite as per your requirement.
9: How about the shipping cost?
lf your goods is not large we can send goods to you via express such as FEDEX, DHL, EMS,TNT etc. If your goods is large, we will send to you via sea or air, we can quote the price base on FOB,CIF &CNF as you like then you can choose whether use our forwarder or yours.
