Product Description




Features:
Milling drilling, tapping, boring, reaming ;
Head swivels 360,Micro feed precision ;
super high column,Wide and big table,Gear drive, lower noise. ;
heavy-duty tapered roller bearing spindle,Positive spindle lock,Adjustable gibs on table;


Characteristic


1. The machine tool adopts belt drive with low noise. It is suitable for drilling, reaming, reaming and milling on various common materials.

2. The machine tool has 12 speed changes and a wide speed range, which is suitable for the processing of various commonly used soft and hard materials;

3. The spindle box and worktable can be lifted or rotated around the column, which expands the processing range;


4. The fuselage is stable and solid, and the size of the workbench is up to 585 × 190mm；

5. The machine tool can be equipped with multi axis device to drill, expand, ream and tap holes at the same time according to the needs of users.

6. The machine tool can realize vertical and horizontal milling functions; The vertical spindle sleeve has manual and micro feeding;








Specification


Model
DM-45 NC
Max.distance Spindle to table(z axis)
500mm
Max.distance Spindle to table
285mm
Working table size
800x240mm
Work table cross travel
500mm
Working table longitudinal travel
230mm
Spindle taper
MT4
Spindle stroke
120mm
Spindle stroke
70-3360rpm
Max.drilling capacity
F45mm
Max.drilling capacity
F32mm
Moter power
1.1kw
Head tilt left right
±90°
NW/GW
700kg
Package size
1330x1175x2220mm
