QCM Smart Panther Woodworking Machinery Wood Planer Machine | ||||||||||
The QMB23 Four Side Moulder | ||||||||||
Technical Parameter | ||||||||||
Specifications | Unit | QMB623A | QMB523A | QMB723R | QMB623R | |||||
Working width | mm | 20-230 | 20-230 | 20-230 | 20-230 | |||||
Working thickness | mm | 8-160 | 8-160 | 8-160 | 8-160 | |||||
Min.working length(intermittent/continuous) | mm | 840/280 | 840/280 | 840/280 | 720/280 | |||||
Dia of spindle | mm | Φ40 | Φ40 | Φ40 | Φ40 | |||||
Feeding speed | m/min | 6-36 | 6-36 | 6-36 | 6-36 | |||||
Rotation speed of spindle | r/min | 6800 | 6800 | 6800 | 6800 | |||||
Cutter dia of first bottom cutter | r/min | Φ125 | Φ125 | Φ125 | Φ125 | |||||
Left/Right vertical cutter | mm | Φ108-Φ200 | Φ108-Φ200 | Φ108-Φ200 | Φ108-Φ200 | |||||
The first upper cutter | mm | Φ108-Φ180 | Φ108-Φ180 | Φ108-Φ180 | Φ110-Φ180 | |||||
The Second upper cutter | mm | Φ108-Φ180 | / | Φ108-Φ180 | / | |||||
Back bottom cutter | mm | Φ108-Φ230 | Φ108-Φ230 | Φ108-Φ230 | Φ108-Φ230 | |||||
Total power | kW/HP | 47.25/63 | 38.25/51 | 54.75/73 | 47.25/63 | |||||
The First bottom cutter | kW/HP | 5.5/7.5 | 5.5/7.5 | 5.5/7.5 | 5.5/7.5 | |||||
Left vertical cutter | kW/HP | 7.5/10 | 7.5/10 | 7.5/10 | 7.5/10 | |||||
Right vertical cutter | kW/HP | 5.5/7.5 | 5.5/7.5 | 5.5/7.5 | 5.5/7.5 | |||||
The first upper cutter | kW/HP | 7.5/10 | 7.5/10 | 7.5/10 | 7.5/10 | |||||
The second upper cutter | kW/HP | 7.5/10 | / | 7.5/10 | / | |||||
The second bottom cutter | kW/HP | 7.5/10 | 7.5/10 | 7.5/10 | 7.5/10 | |||||
The second right vertical cutter | kW/HP | / | / | 7.5/10 | 7.5/10 | |||||
Feeding motor | kW/HP | 5.5/7.5 | 4/5.5 | 5.5/7.5 | 5.5/7.5 | |||||
Beam lifting motor | kW/HP | 0.75/1 | 0.75/1 | 0.75/1 | 0.75/1 | |||||
Suction hood motor dia. | mm | 6*Φ150 | 5*Φ150 | 7*Φ150 | 6*Φ150 | |||||
Air supply pressure | MPa | 0.6 | 0.6 | 0.6 | 0.6 | |||||
Overall dimensions | mm | 4960*1900*1700 | 4280*1900*1700 | 5380*1860*1760 | 4750*1860*1760 | |||||
Weight | kg | 5600 | 4600 | 6050 | 5650 |
