Оранжевый все 50 Вт 60 80 100 co2 лазерная резка гравировальная машина Золотая

Описание и отзывы

Характеристики

orange all 50w 60w 80w 100w co2 laser cutting engraving machine gold laser cutting machine



1. Drive system with high precision linear guide and slide block, high precision ,wear resistance, small resistance, high speed;arc-gear synchronous belt 3m,stable transmission, strong shock absorption ability and small noise.

2. Red cross accurate position, convenient and quick in finding engraving and cutting position.

3. Equipment with automatic / manual modulation focused laser head, responsive and accurate to ensure sculpture quality.







Cutting Speed	1-70mm/s
Highest Scanning Precision	≤1000DPI
Resolution Ratio	<0.01mm
Location Precision	<0.01mm
Min. Shaping Character Letter	1.0 x 1.0mm
Working Temperature	0-45°C
Working Humidity	5-95%
Power Supply	AC220V±10% /50HZ , AC110V±10%//60HZ
Laser Wave Length	10.6um
Water Cut-off Protection Device	Yes
Work Table	Multifunctional work table and honeycomb work table
Electric Up/down Working Table	Yes
Range of Electric Up-down (Z)	0-300mm
Motor	42 Stepper Motor
Digital Subdivision Stepper Drive	System Supported
DSP Interface	USB 2.0
Auxiliary Device	Exhaust Fan, Exhaust Pipe,Water Pump,Air Pump,User Manual
Optional Accessories	Simple rotation, standard chuck, chiller,auto focus system,Water Protection,CCD camera,Blade work platform



Auto-blowing to protect laser head:

High precision retractable laser head,easy to adjust focal length,equipped with red light positioning system,accurate positioning,reduce material loss.

Brand Stepper Motor:

High operating accuracy,high temperature resistance,can bear the high temperature generated by high-speed operation,and low noise.







Service:

1.Warranty for 3 years.

2. Maintenance for whole life.

3. We will provide the consumable parts at an agency price.

4. 24 hours online service,free technical support.

5. Machine has been adjusted before delivery, operation disk is included in the delivery. If there is any other questions, pls kindly tell me.

6. We have manual instruction and CD/U disk for software installation,operation and machine's using and maintenance.
