Мультиметр UT181A с измерением истинных среднеквадратичных значений и функцией отслеживания
- Категории: Electrical Instruments >>>
- Поставщик: Run,Test,Electric,Manufacturing,Co.,Ltd
Поделиться:
Описание и отзывы
Характеристики
Product Paramenters
Specifications | Range | UT181A | ||
DC voltage (V) | 1000V | ±(0.025%+5) | ||
AC voltage (V) | 1000V | ±(0.3%+30) | ||
DC current (A) | 10A | ±(0.08%+10) | ||
AC current (A) | 10A | ±(0.6%+20) | ||
Resistance (Ω) | 60MΩ | ±(0.05%+2) | ||
Admittance (nS) | 60nS | ±(2%+10) | ||
Capacitance (F) | 60mF | ±(2%+5) | ||
Frequency (Hz) | 10Hz~60MHz | ±(0.01%+5) | ||
Temperature (°C) | -40°C~1000°C | ±(1%+30) | ||
Temperature (°F) | -40°F~1832°F | ±(1.5%+50) | ||
Features | ||||
Display count | 60000 | |||
Auto/Manual range | √ | |||
Bandwidth (Hz) | 100kHz | √ | ||
AC+DC/Continuity buzzer | √ | |||
Low pass filter | 1kHz | √ | ||
dBV/dBm | √ | |||
Diode | Around 3V | √ | ||
Duty cycle | 10%~90% | √ | ||
Dual temperature measurement | T1, T2, T1-T2, T2-T1 | √ | ||
Data hold/Peak hold | √ | |||
Relative mode | √ | |||
Data logging | 20000 | √ | ||
Trend capture | √ | |||
MAX/MIN/AVG | √ | |||
Data time display/Data comparison | √ | |||
Backlight adjustment | √ | |||
Analog bar graph/USB interface | √ | |||
Mis-plug alarm | √ | |||
Battery indication/Auto power off | √ | |||
Rechargeable battery | √ | |||
Input protection | √ | |||
Input impedance for DCV | ≥10MΩ | √ | ||
Products Description
Power | Li-ion battery: 7.4V 2200mAh | ||
Display | 3.5-inch 64K color TFT LCD (320 x 240) | ||
Product color | Red and grey | ||
Product net weight | 638.6g | ||
Product size | 225mm x 103mm x 59mm | ||
Standard accessories | Battery, test leads, temperature adaptor socket, point contact temperature probes, power adaptor socket, power adaptor, PC software CD, USB interface cable | ||
Standard individual packing | Gift box, carrying bag, English manual | ||
Standard quantity per carton | 20pcs | ||
Standard carton measurement | 480mm x 385 mm x 505mm | ||
Standard carton gross weight | 25.3kg | ||
Optional accessory | Bluetooth adaptor (UT-D07) | ||
Feature
1. Trend capture2. Data logging: 20000
3. Data comparison
4. 3.5-inch 64k color TFT LCD
5. Dual temperature measurement
6. Low pass filter
7. 2200mAh Li-ion battery
8. Real time and date
9. Peak hold
10. Bluetooth/APP
11.USB interface cable /PC software CD
12. IP65
3. Data comparison
4. 3.5-inch 64k color TFT LCD
5. Dual temperature measurement
6. Low pass filter
7. 2200mAh Li-ion battery
8. Real time and date
9. Peak hold
10. Bluetooth/APP
11.USB interface cable /PC software CD
12. IP65
