4 ~ 20mA Выход давления и температуры PID Регулятор Множественная функция HT-10 для

Описание и отзывы

Характеристики

4~20mA Output Temperature and Pressure PID Controller Multiple Function HT-10 for egg incubator

4~20mA Output Temperature and Pressure PID Controller Multiple Function HT-10 for egg incubator



- Product Features -

1. Temperature Measuring Range: 0-99

2. Temperature Measurement Accuracy: ±0.1

3. Humidity Measurement Range: 0—99%RH

4.Humidity Accuracy: ±3%RH

5.Number of signal-output: 7, (over-temperature, temperature control, insufficient temperature, egg left-turning, egg right-turning, humidity control, alarm)

6.The maximum output load current: temperature control, insufficient temperature ≤ 8A/AC220V, over-temperature, egg left-turning, egg right-turning, humidity control, alarm ≤ 1A / AC22

7.Number of egg-turning: the maximum record is 999 times.

8.cycle of egg-turning: adjustment of 0 – 999 minutes (the factory default is 90 minutes)

9.egg-turning time: adjustment from 0 to 999 seconds (the factory default is 180 seconds)

10.ventilation cycle: from 0 to 999 minutes
(the factory default is 120 minutes)

11.ventilation time: from 0 to 999 seconds (the factory default is 30 seconds)

12.Temperature measurement length: About 2 meters

-Function-



1	Digital displaying of temperature,humidity
2	Full automatically temperature controlling
3	Full automatically humidity controlling
4	Full automatically eggs turning
5	Full automatically alarming
6	Full automatically ventilator
7	Back emergency system
