80 Вт 100 130 150 180 1610 двойная лазерная головка резка древесины машина
2 590,00-3 800,00 $
Стойка оси Y X ремень Автоматическая подача лазерная машина 1410 1610 100 Вт 130 150 резка co2 гравер Leadshine драйвер шаговый
- Категории: >>>
- Поставщик: Liaocheng,Hengchunyuan,Machinery,Equipment,Co.,Ltd.Liaocheng,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Auto Feeding Laser Machine 1410 1610 100W 130W
150W laser cutting co2 laser machine engraver
Main features of Stepmores 1410 1390 1610 Co2 laser cutting engraving machine
1. Co2 laser engraving cutting machine with 1400mm*1000mm working area is good choice.
2. China top brand Reci laser tube.
3. Auto up-down system is suitable for different thickness objects.
4. Twin tables - blade table and honeycomb table can be easily changed.
5. Ruida control system with usb interface.
2. China top brand Reci laser tube.
3. Auto up-down system is suitable for different thickness objects.
4. Twin tables - blade table and honeycomb table can be easily changed.
5. Ruida control system with usb interface.
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads
Laser Cutting Machine for Shoes Shole Upper Material Leather Fabric
1812 Denim Jeans Intelligent 100W Co2 Laser Engraving
Cutting Machine 1610 1410 Engraver Cover Auto Cutting Machine 1410 Engrave Non Metal
CNC Co2 Laser Engraving Cutting Machine Specification
Auto Cutting Machine 1410 Co2 Laser Engraving Cutting Machine Engrave Non Metal Factory Price
| TYPE | FL-1390/FL-1410/FL-2513/FL-1530 |
| Working Area | 1300mm*900mm/1400*1000MM/2500*1300MM/1500*3000MM |
| Laser Power | 80w(100W/130W/150W/180W is optional) |
| Max cutting thickness | 12MM plywood and acrylic at one time |
| Laser Type | EFR OR RECI Brand Glass CO2 laser tube--the best made in China |
| Transmitting Parts | Timing Belt |
| HIWIN Linear Guide Rail--the best made in Taiwan | |
| Drive Type | LeadShine 3-ph Stepper Driver and Motor--the best made in China |
| Default Software / Controller | Laserwork / DSP Control from LeadShine |
| Max. Engraving Speed | 0-1000mm/s |
| Max. Cutting Speed | 0-600mm/s |
| Positioning Accuracy | 0.01mm Max |
| Maximum forming character | English:1 x 1mm |
| Power Supply | 220V±10% 50HZ or 110V±10% 60HZ |
| Software Supported | Adobe Illustrator (AI), ArtCut, CorelDraw, PhotoShop, AutoCAD |
| Graphic Format Supported | PLT, DXF, BMP, JPG, GIF, PGN, TIF and so on |
| Machine configuration | 1.220V±10% 50HZ or 110V±10% 60HZ |
| 2.80W laser power tube | |
| 3.Ruida control system(mother board and panel) | |
| 4.LeadShine motor drive system | |
| 5.HIWIN linear guide rail | |
| 6.red dot position, Red pointer can help you find the engrave position quickly. | |
| 7.DSP control system | |
| 8.moterized up and down working table | |
| 9. Auto feeding bed worktable | |
| 10. 1×Air Pump(installed inside the machine) for Air Assist (for blowing off debris as the laser engrave or cut) | |
| 11. 1×Exhaust(installed inside the machine) with Tube ducts ( for extracting gases from the work area) | |
| 12. 1×Water chiller CW-3000 | |
| 13. 1×USB Cable (connecting PC and laser) | |
| 14. 1×DVD (Including software, User manual, Guiding videos etc.) | |
| 15. 1×Power Cable | |
| 16. 1×Tool box | |
| Optional | 1.auto focus |
| 2.rotary device | |
| 3.up and down working table | |
| 4.as your demand | |
| Thickness | Thickness: Varies by material, MAX 12mm Acrylic one time. |
| Cuts & Engraves | wood/fabric/ leather/paper/cardboard/ plexiglas (acrylic)/Delrin (acetal)/mylar/rubber…and more |
| Engraves Only | glass/marble/rubber stamps/stoneceramic tile/anodized aluminum/titanium/corian …and more |
| Warranty | The warranty for whole machine is effective 1 years from the Ex-Factory Date. But for the laser tube and focus lens and the reflective mirrors, the warranty is 3months.this is the warranty of the manufacture to us. |
| Working video | auto feeding laser machine to cut cloth/fabric, china auto feeding laser machine, flash laser |
| https://www.youtube.com/watch?v=R8JfS0_eQ9g | |
| https://www.youtube.com/watch?v=cfThJqOwNvc | |
| https://www.youtube.com/watch?v=xl1w21UGHfc | |
| https://www.youtube.com/watch?v=GbI8qBaQdhs | |
| https://www.youtube.com/watch?v=ah7SNFpQcn4 | |
| https://www.youtube.com/watch?v=jfdH0MLnvUU |
100w 130w CO2 Laser Leather Cutting Engraving Shoes Making 1390
1410 Double Laser Heads Auto Feeding Cutter Machine Cover Auto Cutting Machine
1410 Engrave Non Metal CNC Co2 Laser Engraving Cutting Machine Factory Sale
1812 Denim Jeans Intelligent 100W Co2 Laser Engraving Cutting Machine 1610 1410 Engraver
the machine table can be lifted in Z direction (up-and-down) to get more working space.
It is necessary if you use rotary or engrave/cut items thicker/higher than 35mm.
2. Rotary (2 types)
It is used to hold and rotate cylindrical items during engraving and cutting,
such as wine bottles, glasses, mugs, pipes, etc.
3. Red dot
Laser is invisible. Red dot shows the laser position on material, for better locating.
4. Auto focusing
Auto focusing has to work together with motorized up-down table.
The machine adjusts the focal length automatically before engraving and cutting,
which replaces manual focusing, improving working efficiency.
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads
Laser Cutting Machine for Shoes Shole Upper Material Leather Fabric
Product details
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads
Cover Auto Cutting Machine 1410 Engrave Non Metal CNC Co2 Laser Engraving Cutting Machine Factory Sale
100w 130w CO2 Laser Leather Cutting Engraving Shoes Making 1390 1410 Double Laser Heads Auto Feeding Cutter Machine
100w 130w CO2 Laser Leather Cutting Engraving Shoes Making 1390 1410 Double Laser Heads Auto Feeding Cutter Machine
Big Cutting Area Laser Engraving Machine 1410 1610 1810 CO2 100w 130w 150w Granite Stone Laser Cutting Machine
1812 Denim Jeans Intelligent 100W Co2 Laser Engraving Cutting Machine 1610 1410 Engraver
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads Laser Cutting Machine
Cover Auto Cutting Machine 1410 Engrave Non Metal CNC Co2 Laser Engraving Cutting Machine Factory Sale
1812 Denim Jeans Intelligent 100W Co2 Laser Engraving Cutting Machine 1610 1410 Engraver
CO2 laser engraving machine Applicable industries:
Model industry (construction models, aviation and navigation models
and wooden toys), advertising, decoreation,arts and crafts,
electronics and electric appliances, etc.
CO2 laser engraving machine Applicable Materials:
Double color sheet, acrylic, glass, wood, mdf, bamboo ware, coconut shells, paper,
leather, cloth, marble, ceramic tile, shells and other nonmetal materials.
Big Cutting Area Laser Engraving Machine 1410 1610 1810 CO2 100w
130w 150w Granite Stone Laser Cutting Machine
Cover Auto Cutting Machine 1410 Engrave Non Metal CNC Co2 Laser Engraving Cutting Machine Factory Sale
Please refer to those info to choose correct laser power or what materails and thickness to cut.
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads Laser
Cutting Machine for Shoes Shole Upper Material Leather Fabric
1812 Denim Jeans Intelligent 100W Co2 Laser Engraving Cutting Machine 1610 1410 Engraver
Big Cutting Laser Engraving Machine 1410 1610 1810 CO2 100w 130w 150w Granite Stone Laser Cutting Machine
Packing List
1.Machine
2.Document bag
3.Air exhaust tube
4.USB Connect cable
5.USB Dongle
6.Key
7.CD with software
8.Power cable, UK/ EU/ US/ AU plug
9.Water chiller CW5000
10.exhauster fan 550W
11.Fixing girdle
12.Double-sided adhesive
13. Honeycomb or Knife platform
Big Cutting Area Laser Engraving Machine 1410 1610 1810 CO2 100w
130w 150w Granite Stone Laser Cutting Machine 1610 1410 Engraver
100w 130w CO2 Laser Leather Cutting Engraving Shoes Making 1390 1410 Double Laser Heads Auto Feeding Cutter Machine
Package Type:
Our laser machines wooden box package include 3 layers:
1.Outside package:Polywood case with metal belt
2.Middle package:We use foam to cover the machine
3.Inner package:We use waterproof plastick bag to cover all the machine.
The laser machine is packed with all the spare parts in the wood case.
We deliver the mini machines of small number by express such as DHL,TNT,UPS,FedEx,etc.
For large-scale engraving cutting machines,we ship the goods by sea.
Big Cutting Area Laser Engraving Machine 1410 1610 1810 CO2 100w 130w 150w Granite Stone Laser Cutting Machine
1812 Denim Jeans Intelligent 100W Co2 Laser Engraving Cutting Machine 1610 1410 Engraver
Our Service and Factory
Liaocheng Hengchunyuan Laser Machinery supply free technical training for all customers
all overthe world until the workers from buyer can operate the machine normally and individually.
Key Features of non metal cutting machine
1.Open type working table achieves large format engraving and cutting area
2.dust helmet keeps linear guide rail clean and smooth, which extends machine lifespan
3.Guide rail grooves is one piece type and made by milling machine.
Light patch won't be changed after long time using,
which makes the whole machine more stable and cutting more precise
4.whole machine with stable mechanical design, ensure high stability, high speed and high prescison
5.honeycomb table and with thicker Znfe focus lens, more durable and smooth.
Laser pathsystem use Mo mirror imported lens ,
which keeps the same power output at any site on working table
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads Laser
Cutting Machine for Shoes Shole Upper Material Leather Fabric
100w 130w CO2 Laser Leather Cutting Engraving Shoes Making 1390 1410 Double Laser Heads Auto Feeding Cutter Machine
Cover Auto Cutting Machine 1410 Engrave Non Metal CNC Co2 Laser Engraving Cutting Machine Factory Sale
Hengchunyuan Machinery Equipment Co., Ltd. Advantages of laser cutting machine
1.FL - 1390 CO2 laser engraving machine fast engraving and cutting speed, high precision.
Can be configured with up-down lifting table, honeycomb table, rotary, etc.
2.Machine working size can be selected according to your needs.we have 600x400mm,
900x600mm, 1300x900mm, 1400x900mm, 1600x1000mm, 1300x2500mm and so on.
Also we can customize it for you.
Big Cutting Area Laser Engraving Machine 1410 1610 1810 CO2 100w 130w
150w Granite Stone Laser Cutting Machine
Auto Feeding Laser Machine 1610 1810 1812 4 Laser Heads Laser Cutting Machine Fabric
FAQ
Q: Why choose us?
A: If you choose us, you will get best quality,best service,best price,best warranty.
Q: How to operate the machine?
A: We will deliver English manual and video with the machine to you.
If you still need our help,please contact us.
Q: How can I get the sample to check you quality?
A: If you want to marking sample to check the quality, we can help you do this.
first you need to provide the logo or design to us, free mark samples can be provided.
Q: Does the machine can be customized according my requirements?
A: Sure,we have a strong technical team and have rich experience.
Our goal is to make you satisfied.
Q: Can you arrange shipping for me?
A: We can arrange shipping for our clients accordingly by sea and air.
Trading terms FOB, CIF, EXW are available.
Please provide the following information, I will make recommendations for you:
(1) What do you engrave / cut?
(2) What is your Item/material/product size (length and width)?
(3) What is your Item/material/product width?
(4) Please specify if you have special requirements.
Welcome to enquiry and visit our factory!
Wendy Li Whatsapp / Wechat: 0086 19953859052
email: wendyli(@)hcylaser.com Website: www.flashlasercnc.com
Auto Cutting Machine 1410 Co2 Laser Engraving Cutting Machine Engrave Non Metal Factory Price
Auto Feeding Laser Machine 1410 1610 100W 130W
150W laser cutting co2 laser machine engraver
