Performance item | Test condition | Testing method | Test Data | ||
Basic performance | Density | ISO 1183 | 0.932 g/cm3 | ||
Melt Flow Rate | 190℃/2.16kg | ISO 1133 | 4 g/10min | ||
Mechanical behavior | Tensile Strength | IS0 527 | 11 N/mm2 | ||
Modulus of Elasticity | IS0 527 | 260 N/mm2 | |||
Drop Impact Strength | ASTM D-1709 | 100g | |||
Maximum Tensile Strength (MD) | IS0 527 | 22MPa | |||
Maximum Tensile Strength (TD) | IS0 527 | 15MPa | |||
Ultimate Elongation (MD) | IS0 527 | 300% | |||
Ultimate Elongation (TD) | IS0 527 | 600% | |||
Thermal performance | DSC (differential scanning calorimeter) Melting Temperature | Basel Method | 111℃ | ||
Vicat Softening Point | ISO 306 | 92℃ | |||
Other properties | Film Thickness | 50 | |||
Turbidity | ASTM D-1003 | <7% | |||
Optical properties | Glossy | 20° | DIN 67350 | >90 |
