Yanan Pem водородный топливный элемент 1 кВт Электрогенератор высокого качества для
- Категории: >>>
- Поставщик: Fujian,Fuan,Mindong,Yanan,Electrical,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Details
Hydrogen Fuel Cell System Technical Data
Hydrogen Fuel Cell System (Air Cooling) 0.2kW~5kW | ||||||||||||
Model | RBZ-0.2K | RBZ-0.4K | RBZ-1K | RBZ-2K | RBZ-3K | RBZ-5K | ||||||
Rated Power(kW) | 0.2 | 0.4 | 1 | 2 | 3 | 5 | ||||||
Power Generation (kW.h/1m³H₂) | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | ||||||
AC Output | 220V ACV/0.9A | 220V ACV/1.8A | 220V ACV/4.5A | 220V ACV/9.2A | / | 220V ACV/22.7A | ||||||
DC Output | / | / | / | 12V/10A 5V/3A | 48V/63A | / | ||||||
Fuel | H₂, 0.05/0.2MPa, 99.99% | |||||||||||
Hydrogen Consumption (L/min) | ≤ 3 | ≤ 5 | ≤ 12 | ≤ 25 | ≤ 35 | ≤ 60 | ||||||
Energy Conversion Efficiency | 40%~60% | |||||||||||
Cooling Method | Air Cooling | |||||||||||
Noise Level | ≤ 60dB | ≤ 65dB | ||||||||||
Hydrogen Fuel Cell System (Water Cooling) 6kW~30kW | ||||||||||||
Model | RBZ-6K | RBZ-10K | RBZ-12K | RBZ-15K | RBZ-20K | RBZ-30K | ||||||
Rated Power(kW) | 6 | 10 | 12 | 15 | 20 | 30 | ||||||
Power Generation (kW.h/1m³H₂) | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | 1.3 | ||||||
AC Output | 220V ACV/27.3A | 220V ACV/45.5A | 220V ACV/54.5A | 220V ACV/68.2A | 220V ACV/77.3A | 180V ACV/166.6A | ||||||
Fuel | H₂, 0.05/0.2MPa, 99.99% | |||||||||||
Hydrogen Consumption (L/min) | ≤ 70 | ≤ 120 | ≤ 130 | ≤ 180 | ≤ 240 | ≤ 400 | ||||||
Energy Conversion Efficiency | 40%~60% | |||||||||||
Cooling Method | Water Cooling | |||||||||||
Noise Level | ≤ 65dB | ≤ 75dB | ||||||||||
